C0-08TR-3 CLICK Expansion I/O Module
Equivalent Circuit Diagram:
24VDC
240VAC
OUTPUT
Load
COM
Dimensional Drawings
8.5
0.33
85.0
3.35
Copyright© 2020, Automationdirect.com Incorporated/All Rights Reserved Worldwide
www.automationdirect.com/click-plc
Internal Module Circuitry
24V
37.0
12.0
1.46
0.47
13-WIRE CONNECTOR
Wiring Diagram:
75.0
2.95
CLK-3
CLICK Module Insert
3505 HUTCHINSON ROAD
CUMMING, GA 30040-5860
44.3
1.74
40.7
1.60
Dimensions: mm
[inches]
1-800-633-0405
