Ingersoll-Rand 9115 Instructions Manual

Model 9115 Sprayer is designed for paint, lacquer, stain or other finish type material.
• IMPORTANT SAFETY INFORMATION ENCLOSED - SAVE THESE INSTRUCTIONS
• READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS PRODUCT
• IT IS YOUR RESPONSIBILITY TO MAKE THIS SAFETY INFORMATION
AVAILABLE TO OTHERS THAT WILL OPERATE THIS PRODUCT
• FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY
PLACING THE PAINT SPRAYER IN SERVICE
• Always install, operate, inspect and
maintain this product in accordance with
all applicable standards and regulations
(local, state, country, federal, etc.).
• Always use clean, dry air at 43 psig
maximum air pressure at the inlet. Higher
pressure may result in hazardous
situations.
• Be sure all hoses and fittings are the
correct size and are tightly secured. See
Dwg. TPD905-2a for a typical piping
arrangement.
• Ensure an accessible emergency shut off
valve has been installed in the air supply
line, and make others aware of its location.
• Do not use damaged, frayed or
deteriorated air hoses and fittings.
• Keep clear of whipping air hoses. Shut off
the compressed air before approaching a
whipping hose.
• Always wear eye protection when operating
or performing maintenance on this
product.
• Always use Personal Protective Equipment
appropriate to the product used and
material worked. This may include dust
mask or other breathing apparatus, safety
glasses, ear plugs, gloves, apron, safety
shoes, hard hat and other equipment.
• When wearing gloves always be sure that
the gloves will not prevent the controls
from being operated.
• Keep others a safe distance from your
work area, or ensure they use appropriate
Personal Protective Equipment.
• This product is not insulated against
electric shock.
• Do not point the spray gun at anyone or
any part of the body.
Refer All Communications to the Nearest
Ingersoll-Rand Office or Distributor.
© Ingersoll-Rand Company 2003
Printed in Taiwan
INSTRUCTIONS FOR
MODEL 9115
HVLP GRAVITY FEED SPRAYER
USING THE PAINT SPRAYER
• Always turn off the air supply, bleed the air
pressure and disconnect the air supply
hose before installing, removing or
adjusting any accessory on this product, or
before performing any maintenance on
this product or any accessory.
• Do not lubricate products with flammable
or volatile liquids such as kerosene, diesel
or jet fuel. Use only recommended
lubricants.
• Use only proper cleaning solvents to clean
parts. Use only cleaning solvents which
meet current safety and health standards.
Use cleaning solvents in a well ventilated
area.
• Keep work area clean, uncluttered,
ventilated and illuminated.
• Do not remove any labels. Replace any
damaged label.
• Do not stop or deflect spray with your
hand, body, glove, or rag.
• Repetitive motions or uncomfortable
positions may be harmful to your hands
and arms. Stop using any product if
discomfort, tingling feeling or pain occurs.
Seek medical advice before resuming use.
• Keep body stance balanced and firm. Do
not overreach when operating this
product.
• To avoid accidental starting - ensure
product is in "off" position before applying
power, avoid throttle when carrying, and
release throttle with loss of air.
• Do not carry or drag this product by the
hose.
• Do not use this product when tired, or
under the influence of medication, drugs,
or alcohol.
Form P7744
FR
Edition 1
December, 2003
ES
CCN 04580668
