BRAND
Assembly Instructions
500Lb Protein Feeder
Style # 165840 (HU2339801-GW)
Please keep this instruction manual for future reference
Customer Service: 1-888-837-1380, 8:00am to 5:00pm, Pacific Standard Time,
Monday thru Friday
Email: customerservice@rankam.com
-------- OR --------
Customer Service: 1-888-922-2336, 7:00am to 12:00am CST daily
Live Chat at: www.academy.com
Email: customerservice@academy.com
(Made in China)
HU2339801-GW
Pg.1
20210304-V1.0
Advertisement
Table of Contents
Related Manuals for Game Winner 165840
Summary of Contents for Game Winner 165840
- Page 1 BRAND Assembly Instructions 500Lb Protein Feeder Style # 165840 (HU2339801-GW) Please keep this instruction manual for future reference Customer Service: 1-888-837-1380, 8:00am to 5:00pm, Pacific Standard Time, Monday thru Friday Email: customerservice@rankam.com -------- OR -------- Customer Service: 1-888-922-2336, 7:00am to 12:00am CST daily Live Chat at: www.academy.com...
-
Page 2: Table Of Contents
Table of Contents Page Warnings -------------------------------------------------------------------------- Parts List -------------------------------------------------------------------------- Hardware List -------------------------------------------------------------------- Tools required (not included) ---------------------------------------------- Product Diagram --------------------------------------------------------------- Assembly Instructions ------------------------------------------------------- 11-14 How to load your feeder ----------------------------------------------------- Care and Maintenance -------------------------------------------------------- Replacement Parts------------------------------------------------------------- Warranty -------------------------------------------------------------------------- 18-19 NOTE: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. -
Page 3: Warnings
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. YOUR GAME WINNER 500LB PROTEIN FEEDER IS DESIGNED, ENGINEERED AND CONSTRUCTED IN A MANNER THAT MAKES IT A RUGGED PIECE OF HUNTING EQUIPMENT THAT WILL GIVE YOU YEARS OF SERVICE. THIS RUGGED CONSTRUCTION MAKES YOUR FEEDER PHYSICALLY HEAVY. - Page 4 Warnings DO NOT LOAD FEEDER WITHOUT ANOTHER ADULT. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS INJURY OR DEATH! DO NOT LOAD FEEDER DURING BAD WEATHER SUCH AS STORMS, SNOW, LIGHTNING, OR THUNDERSTORMS. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULTS IN SERIOUS INJURY OR DEATH! DO NOT SIT OR STAND ON OR INSIDE THE HOPPER.
- Page 5 Warnings ! IMPORTANT ! THE MANUFACTURER OF THE 500LB PROTEIN FEEDER IS NOT RESPONSIBLE FOR ANY INACCURATE INFORMATION YOU HAVE RECEIVED REGARDING STATE FEEDING REGULATIONS. PLEASE ALWAYS KEEP YOUR INFORMATION UP-TO- DATE AND RELIABLE. MANY STATE LAWS CHANGE AND ARE AMENDED WITHOUT NOTICE. ALWAYS DOUBLE CHECK YOUR STATE AND SPECIFIC COUNTY FEEDING LAWS REGARDING THE USE OF FEEDERS.
-
Page 6: Parts List
Parts List 1 pc 1a –catcher – 2 pcs (pre-attached on lid) 1a catcher 2A Top Hopper 2B Bottom Hopper Hopper 1 set Lock Latch 2 pcs Feed Spout 4 pcs Upper Leg 4 pcs 4 pcs Lower Leg HU2339801-GW Pg.6 20210304-V1.0... - Page 7 Parts List Support Bar 2 pcs Leg Skid Blade - A 2 pcs Leg Skid Blade - B 2 pcs Stake 4 pcs HU2339801-GW Pg.7 20210304-V1.0...
-
Page 8: Hardware List
Hardware List Hex. Bolt (M8x20) 8 pcs 52 pcs Hex. Bolt (M8x15) Flat Washer (dia. 8mm) 92 pcs Lock Nut (M8) 32 pcs Bolt M4x10 4 pcs Lock Nut (M4) 4 pcs HU2339801-GW Pg.8 20210304-V1.0... -
Page 9: Tools Required (Not Included)
Tools Required (not included) Philips & Flathead Screwdrivers Pliers Wrench HU2339801-GW Pg.9 20210304-V1.0... -
Page 10: Product Diagram
Product Diagram HU2339801-GW Pg.10 20210304-V1.0... -
Page 11: Assembly Instructions
Assembly Instructions Step 1: Attach Feed Spouts (#4) to base of Bottom Hopper (#2B) using bolts (B, M8x15), washers (C, 8 mm). Tighten bolts with tool Hardware : #B - 12 pcs #C - 12 pcs Step2: Attach Upper Legs (#5) to previous hopper assembly using bolts (B, M8x15), washers (C, 8 mm) and... - Page 12 Assembly Instructions Step 3: Simultaneously attach Lower Legs (#6) and Support Bars (#7) to previous hopper assembly using bolts (A, M8x20), washers (C, 8mm) and lock nuts (D, M8). Hand Tighten bolts and nuts in this step Hardware : #A - 8 pcs #C - 16 pcs #D - 8 pcs Step 4:...
- Page 13 Assembly Instructions Step 5: Attach Leg Skid Blade assemblies in previous step to Lower Legs using bolts (B, M8x15), washers (C, 8 mm) and lock nuts (D, M8). *Lower Legs sit on Leg Skid Blades Tighten all bolts and nuts in this step and in steps 2,3 with tool Hardware :...
- Page 14 Assembly Instructions Step 7: Attach Top Hopper (#2A) to Bottom Hopper (#2B) using bolts (B, M8x15) and washers (C, 8mm). Tighten bolts and nuts with tool Hardware : #B - 16 pcs #C - 16 pcs Step 8: Put Lid (#1) onto hopper and lock with Latch Lock (#3).
-
Page 15: How To Load Your Feeder
HOW TO LOAD YOUR FEEDER OPEN THE LID AND POUR FEED INTO THE HOPPER. AFTER FILLING, CLOSE THE LID. TIPS & POINTERS: (Q) What kind of feed should I use? (A) Whole kernel corn is recommended. Whole kernel corn mixed with soybeans or pellets is also effective for attracting deer. -
Page 16: Care And Maintenance
Care and Maintenance • INSPECT FEEDER FOR ANY LOOSE PARTS OR HARWARE REGULARLY • CHECK IF FEEDER IS TAKING WATER ON RAINY DAYS. SEAL GAP WITH SILICONE SEALANT IF NECESSARY • IF RUST APPEARS ON THE EXTERIOR SURFACE OF FEEDER, CLEAN AND BUFF THE AFFECTED AREA WITH STEEL WOOL OR FINE GRIT SAND PAPER / EMERY CLOTH. -
Page 17: Replacement Parts
Replacement Parts Part Number Component Part Name MET-CF0017 MET-CF0018 Top Hopper MET-CF0019 Bottom Hopper MET-CF0020 Lock Latch MET-CF0021 Feed Spout MET-CF0022 Upper Leg MET-CF0023 Lower Leg MET-CF0024 Support Bar Leg Skid Blade – A MET-CF0025 Leg Skid Blade – B MET-CF0026 MET-CF0027 Stake... -
Page 18: Warranty
Warranty Information Manufacturer warrants this product to be free from defects in workmanship and materials for a period of 90 days from the date of purchase, PROVIDED claims are submitted, in writing, with proof of purchase. If any part of this item fails because of a manufacturing defect within the Limited Warranty Period, manufacturer offers to replace such part(s) provided that such parts have not been improperly repaired, altered, or tampered with or subject to misuse, abuse, or exposed to corrosive conditions. - Page 19 Warranty Information IF CUSTOMER SERVICE IS NECESSARY: The original purchaser is responsible for shipping and handling charges of the returned item(s) and replacement parts, if any. All parts to be replaced will need to be shipped before replacement items will be sent. Follow the customer service representative’s instructions exactly.
