Game Winner HU2220401-GW Assembly Instructions Manual

300lb cube vp feeder

Hide thumbs

Table Of Contents

BRAND

Assembly Instructions

300Lb Cube VP Feeder

Style # 143736 (HU2220401-GW)

Please keep this instruction manual for future reference

Customer Service: 1-888-837-1380, 8:00am to 5:00pm, Pacific Standard Time,

Monday thru Friday

Email: customerservice@rankam.com

-------- OR --------

Customer Service: 1-888-922-2336, 7:00am to 12:00am CST daily

Live Chat at: www.academy.com

Email: customerservice@academy.com

(Made in China)

20200205-V3.1

Pg.1

HU2220401-GW-ENG

Table of Contents

Need help?

Do you have a question about the HU2220401-GW and is the answer not in the manual?

Questions and answers

Summary of Contents for Game Winner HU2220401-GW

Page 1 BRAND Assembly Instructions 300Lb Cube VP Feeder Style # 143736 (HU2220401-GW) Please keep this instruction manual for future reference Customer Service: 1-888-837-1380, 8:00am to 5:00pm, Pacific Standard Time, Monday thru Friday Email: customerservice@rankam.com -------- OR -------- Customer Service: 1-888-922-2336, 7:00am to 12:00am CST daily Live Chat at: www.academy.com...
Page 2: Table Of Contents
14-19 How to load your feeder ----------------------------------------------------- How to install the battery ---------------------------------------------------- How to operate the timer ---------------------------------------------------- Care and Maintenance ------------------------------------------------------- Assembly Instructions of 155060 Game Winner 6V Solar Panel Charger (not included) --------------------------------- 22-23 Warranty -------------------------------------------------------------------------- 24-25 NOTE: Before beginning assembly of product, make sure all parts are present.
Page 3: Warnings
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. Your GAME WINNER 300LB CUBE VP FEEDER IS DESIGNED, ENGINEERED AND CONSTRUCTED IN A MANNER THAT MAKES IT A RUGGED PIECE OF HUNTING EQUIPMENT THAT WILL GIVE YOU YEARS OF SERVICE.
Page 4 COMPLETE CHARGE PRIOR TO THE FIRST TIME OF OPERATION. REFER TO USER INSTRUCTION OF THE BATTERY. THE PROPER SPACING BETWEEN THE SPIN PLATE AND THE FUNNEL IS 3/8 INCH. THIS IS VERY IMPORTANT FOR SERVICE FREE OPERATION. 20200205-V3.1 Pg.4 HU2220401-GW-ENG...
Page 5 BEFORE STANDING UP THE FEEDER, YOU MUST… CHECK ALL HARDWARE TO BE SURE IT IS IN PLACE AND TIGHT. CHECK ALL BOLTS AND NUTS TO BE SURE THEY ARE FIRM AND TIGHT. DO NOT THROW AWAY THE PACKAGING MATERIAL AT THIS TIME. 20200205-V3.1 Pg.5 HU2220401-GW-ENG...
Page 6 REGARDING STATE FEEDING REGULATIONS. PLEASE ALWAYS KEEP YOUR INFORMATION UP-TO- DATE AND RELIABLE. MANY STATE LAWS CHANGE AND ARE AMENDED WITHOUT NOTICE. ALWAYS DOUBLE CHECK YOUR STATE AND SPECIFIC COUNTY FEEDING LAWS REGARDING THE USE OF FEEDERS. 20200205-V3.1 Pg.6 HU2220401-GW-ENG...
Page 7: Tools Required (Not Included)
Tools Required (not included) Philips & Flathead Screwdrivers Pliers Wrench 20200205-V3.1 Pg.7 HU2220401-GW-ENG...
Page 8: Parts List
(pre-attached on hopper) 4b gasket 4a - Rain Diverter 4a rain diverter 1 set 4b - Gasket Door 1 pc (pre-attached on hopper) 1 pc Door Knob (pre-attached on door) Upper Leg 4 pcs Lower Leg 4 pcs 20200205-V3.1 Pg.8 HU2220401-GW-ENG...
Page 9 Parts List Leg Blade 2 pcs Leg Skid Blade - A 2 pcs Leg Skid Blade - B 2 pcs Stake 4 pcs Varmint Guard 1 pc bottom door wing bolts – 2 pcs 20200205-V3.1 Pg.9 HU2220401-GW-ENG...
Page 10: Hardware List
44 pcs Hex. Bolt (M6x20) 13 pcs 44 pcs Locking Nut (M8) 88pcs Flat Washer (dia. 8mm) Flat Washer (dia. 6mm) 8 pcs 2 pcs Bolt M5x12 2 pcs Nut M5 2 pcs Bolt M6x20 (pre-attached on hopper) 20200205-V3.1 Pg.10 HU2220401-GW-ENG...
Page 11: Component & Hardware List For Timer Kit Set
2 pcs ii.) Short conduit – black Digital Timer 1 pc Mounting Bracket 2 pcs Funnel 1 pc Solar Panel Fixture Bracket 1 pc Metal Timer Kit Housing 1 pc R – wing bolt R - wing bolt 20200205-V3.1 Pg.11 HU2220401-GW-ENG...
Page 12 !! Hardware are packed INSIDE the Timer Kit Set package!! Hex. Bolt (M6x20) 10 pcs Flat Washer (dia. 6mm) 2 pcs Butterfly Nut ( M6) 2 pcs Flange Nut (M6) 2 pcs Wing Bolt (M6) 1 pc 20200205-V3.1 Pg.12 HU2220401-GW-ENG...
Page 13: Product Diagram
Product Diagram 20200205-V3.1 Pg.13 HU2220401-GW-ENG...
Page 14: Assembly Instructions
#K – 8 pcs Attention : the conduit connector on side of timer box and the conduit connector at bottom of hopper should be on the same side. See Pg. 20 for proper spacing of spinner plate to funnel (3/8”) 20200205-V3.1 Pg.14 HU2220401-GW-ENG...
Page 15 Guard. Timer Kit door Attach the Varmint Guard should align to door of (#12) to the bottom of Varmint Guard hopper using bolts (B, M6x20) and flat washers (E, 6mm). Hardware : #B - 8 pcs #E - 8 pcs 20200205-V3.1 Pg.15 HU2220401-GW-ENG...
Page 16 Upper Legs (#7) using bolts (A, M8x15), flat washers (D, 8 mm) and locking nuts (C, M8). DO NOT TIGHTEN bolts and nuts in this step. Hardware : #A - 16 pcs #C - 16 pcs #D - 32 pcs 20200205-V3.1 Pg.16 HU2220401-GW-ENG...
Page 17 (#10A & #10B) using bolts (A, M8x15), flat washers (D, 8mm) and locking nuts (C, M8). DO NOT TIGHTEN bolts and nuts in this step. Hardware : #A - 4 pcs #C - 4 pcs #D - 8 pcs 20200205-V3.1 Pg.17 HU2220401-GW-ENG...
Page 18 Hardware : #A - 4 pcs #C - 4 pcs #D - 8 pcs Step 10: Attach Rain Diverter (#4a) and Gasket (#4b) to the hopper (above door) using bolts (B, M6x20) Hardware : #B - 5 pcs 20200205-V3.1 Pg.18 HU2220401-GW-ENG...
Page 19: How To Load Your Feeder
(A) Whole kernel corn is recommended. Whole kernel corn mixed with soybeans or pellets is also effective for attracting deer. NOTE: When not mixed with corn, some types of pellets can take on moisture and clog the feeder. 20200205-V3.1 Pg.19 HU2220401-GW-ENG...
Page 20: How To Install The Battery
READ THE OPERATION MANUAL INCLUDED IN THE TIMER KIT UNIT. THE PROPER SPACING BETWEEN THE SPIN PLATE AND THE FUNNEL IS 3/8 INCH (0.953 cm). THIS IS VERY IMPORTANT FOR SERVICE- FREE OPERATION. 3/8” / 0.953 cm 20200205-V3.1 Pg.20 HU2220401-GW-ENG...
Page 21: Care And Maintenance
• CLEAN FEEDER HOPPER REGULARLY TO AVOID CLOGGING AND DAMAGE TO THE CONTROL UNIT ATTENTION •IF USING THE GAME WINNER TIMER AS A REPLACEMENT TIMER, IT WILL WORK WITH EITHER 6V OR 12V MOTORS. IF USING A 6V MOTOR, USE A 6V BATTERY. IF USING 12V MOTOR, USE A 12V BATTERY.
Page 22: Assembly Instructions Of 155060 Game Winner 6V Solar Panel Charger (Not Included)
Solar Panel before loading or when it is empty. Hardware: #SP3 - 2 pcs For use of NON-Game Winner Solar Panel Charger (not included), follow below instructions Attach Solar Panel Fixture Bracket (#17) on side of Solar Panel Fixture Bracket hopper using bolts (SP3, M6x20).
Page 23 Assembly Instructions of 155060 Game Winner 6V Solar Panel Charger (not included) Non-Game Winner 6V Solar Panel Charger Assembly (not included) Attach NON-Game Winner Solar Panel Charger Solar Panel Fixture Bracket using bolts (SP1, M5x12) and nuts (SP2, M5). Hardware:...
Page 24: Warranty
- Discoloration or loss of paint due to handling during assembly, heat or cleaning products. Paint may require touch up. - Stainless steel discoloration or corrosion - Consumables such as batteries - Damages caused by wild game 20200205-V3.1 Pg.24 HU2220401-GW-ENG...
Page 25 Rankam (China) Manufacturing Co. Ltd. 18/F., New Lee Wah Centre, 88 Tokwawan Road, Kowloon, Hong Kong Please contact Rankam Customer Service at customerservice@rankam.com or at 1-888-837-1380, Mon to Fri, 8:00 a.m. – 5:00 p.m. Pacific Standard Time. 20200205-V3.1 Pg.25 HU2220401-GW-ENG...
