Summary of Contents for Mi Basic S
- Page 1 Read this manual carefully before use, and retain it for future reference. Product Overview Charging Case Micro USB Charging Port Charging Pins Charging Indicator...
- Page 2 Earbuds Multi-function Button Indicator Microphone Charging Contact Points The earbuds come with the size M of ear tips installed, you can switch to size S or L if the installed size does not suit your ear.
- Page 3 Wearing Gently insert the earbud into the ear canal, make sure it is not easy to sway when shaking your head. Please pay attention to adjust the earbud to expose the microphone during calls.
- Page 4 Charging Before using the device, please tear off the protective film from the earbuds' contact points to fully charge them and their charging case. Protective Film Connect the charging cable to charge the earbuds and the charging case simultaneously. The indicator is red while charging, and changes to white once fully charged, then goes off after 1 minute.
-
Page 5: Turning Off
Turning On Once you remove the earbud from the charging case, it automatically turns on. In case the earbuds are not in the charging case and turned off, press and hold the multi-function button for 1 second till the indicator turns white. Press and hold for 1 second Indicator turns... - Page 6 Make sure the Bluetooth is enabled on your device. When the indicator of the left or right earbud slowly blinks white, search for "Mi True Wireless EBs Basic S" on your device. 2. Once your device and earbuds are successfully connected, your earbuds will automatically connect to the previously paired device (the Bluetooth is enabled) when they are turned on.
- Page 7 Reset Earbuds If the earbuds cannot connect properly, please carry out the following steps to reset: Remove the earbuds from the charging case, and make sure they are turned off. Press and hold the multi-function button on both earbuds for about 15 seconds.
-
Page 8: Function Overview
Function Overview The following functions can be used on both earbuds: Answer/End calls Gently press the multi-function button to answer/ end calls. Press Reject a call Press and hold the button for 1 second to reject a call. Press and hold for 1 second... - Page 9 Play/Pause Music Press the multi-function button to play/pause the music while using the earbuds. Press Turn On Voice Assistant Double press the multi-function button to enable the voice assistant while using the earbuds. Note: The function of voice assistant and quick wake-up must be supported and enabled on your device.
- Page 10 Answer a Second Call/Switch between Calls Press the multi-function button to answer the second incoming call during an ongoing call. Double press the multi-function button to switch between the two calls. Switch between Earbuds and Device During a call, press and hold the multi-function button for 1 second to switch between the earbuds and your phone.
- Page 11 Precautions Warning 1. Do not disassemble, repair or modify the product for any reason, as this may cause fire or even completely destroy the product. 2. Do not expose the product to environments where the temperature is too low or too high (below 0°C or above 45°C).
- Page 12 Note 1. If the product has not been used for more than 2 weeks, it is recommended to charge the product before use. 2. Only use certified chargers supplied by qualified manufacturers. 3. Continuous use of the earbuds for a long time is detrimental to one's hearing.
-
Page 13: Specifications
Specifications Name: Mi True Wireless Earbuds Basic S Model: TWSEJ05LS Bluetooth Operating Frequency: 2402-2480 MHz (For EU) Max RF Output Power: < 20 mW Earbuds Dimensions: 26.65 × 16.4 × 21.6 mm Net Weight: Approx. 4.1 g (per earbud) Wireless Range:... - Page 14 Hereby, Yingsheng Inc., declares that the radio equipment type TWSEJ05LS is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.mi.com/global/service/support/ declaration.html CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
- Page 15 WEEE Information All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local...
- Page 16 For further information, please go to www.mi.com Manufactured for: Xiaomi Communications Co., Ltd. Manufactured by: Dongguan Yingsheng Electronic Technology Co., Ltd.
