- Page 1 Fridge-freezer [en] User manual KI25.., KI24.., KI23.., KI22..
-
Page 2: Table Of Contents
Table of contents 1 Safety .......... 4 7.2 Operating tips...... 16 1.1 General information.... 4 7.3 Switching off the appliance .. 16 1.2 Intended use....... 4 7.4 Setting the temperature.... 16 1.3 Restriction on user group... 4 8 Additional functions .... 16 1.4 Safe transport ...... 4 8.1 Super function ...... 16 1.5 Safe installation ...... 5 1.6 Safe use ........ 6... - Page 3 14 Troubleshooting....... 24 15 Storage and disposal.... 26 15.1 Taking the appliance out of operation ........ 26 15.2 Disposing of old appliance .. 26 16 Customer Service..... 27 16.1 Product number (E-Nr.) and production number (FD).. 27 17 Technical data ...... 27...
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use This appliance is only intended to be fully fitted in a kitchen. -
Page 5: Safe Installation
Safety en 1.5 Safe installation WARNING ‒ Risk of electric shock! Improper installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. ▶... -
Page 6: Safe Use
en Safety 1.6 Safe use WARNING ‒ Risk of electric shock! An ingress of moisture can cause an electric shock. ▶ Only use the appliance in enclosed spaces. ▶ Never expose the appliance to intense heat or humidity. ▶ Do not use steam- or high-pressure cleaners to clean the appli- ance. - Page 7 Safety en WARNING ‒ Risk of injury! Containers that contain carbonated drinks may burst. ▶ Do not store containers that contain carbonated drinks in the freezer compartment. Injury to the eyes caused by escaping flammable refrigerant and hazardous gases. ▶ Do not damage the tubes of the refrigerant circuit or the insula- tion.
-
Page 8: Damaged Appliance
en Safety 1.7 Damaged appliance WARNING ‒ Risk of electric shock! If the appliance or the power cord is damaged, this is dangerous. ▶ Never operate a damaged appliance. ▶ Never pull on the power cord to unplug the appliance. Always unplug the appliance at the mains. ▶... -
Page 9: Preventing Material Damage
Preventing material damage en – Maintain a 30 mm clearance to Preventing material damage 2 Preventing material electric or gas cookers. – Maintain a 300 mm clearance to damage oil or solid-fuel cookers. ¡ Use a niche depth of 560 mm. Preventing material damage ATTENTION! ¡... -
Page 10: Installation And Connection
en Installation and connection volume of refrigerant is indicated Installation and connection 4 Installation and con- on the rating plate. → "Appliance", nection Fig. , Page 13 The weight of the appliance ex works You can find out where and how best Installation and connection may be up to 55 kg depending on to install your appliance here. -
Page 11: Installing The Appliance
Installation and connection en If the niche depth is smaller, the en- ergy consumption increases slightly. The niche depth must be a minimum 550 mm. Niche width An inside niche width of at least 560 mm is required for the appli- ance. 4.3 Installing the appliance Install the appliance in accordance ▶... -
Page 12: Familiarising Yourself With Your Appliance
en Familiarising yourself with your appliance Familiarising yourself with your appliance 5 Familiarising yourself with your appliance Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. Freezer compartment Variable shelf → Page 14 Refrigerator compartment Extendable shelf → Page 14 Control panel... -
Page 13: Control Panel
Familiarising yourself with your appliance en Fruit and vegetable container Door storage compartment with humidity control for large bottles → Page 14 Note: Deviations between your appli- Rating plate ance and the diagrams may differ with regard to their features and size. Butter and cheese compart- ment → Page 15 5.2 Control panel You can use the control panel to configure all functions of your appliance and... -
Page 14: Features
en Features seal. This allows fresh fruit and veget- Features 6 Features ables to be stored for up to twice as long as with conventional storage. The features of your appliance de- Features pend on the model. 6.1 Shelf To vary the shelf as required, you can remove the shelf and re-insert it elsewhere. -
Page 15: Butter And Cheese Compart- Ment
Features en 6.5 Butter and cheese com- partment Store butter and hard cheese in the butter and cheese compartment. To open the butter and cheese com- partment, press down lightly on the centre of the flap. Note: The compartment opens down- wards. The flap slides under the com- partment. -
Page 16: Basic Operation
en Basic operation The refrigerator compartment tem- Basic operation 7 Basic operation perature influences freezer com- partment temperature. Refrigerator Basic operation compartment temperatures that 7.1 Switching on the appli- are set to warm generate warmer ance freezer compartment temperatures. Press a The appliance begins to cool. Additional functions 8 Additional functions Set the required temperature. -
Page 17: Alarm
Alarm en ¡ Allow hot food and drinks to cool Alarm 9 Alarm down first before placing in the ap- pliance. Alarm 9.1 Door alarm 10.2 Chill zones in the refri- gerator compartment If the appliance door is open for a longer period, the door alarm The air circulation in the refrigerator switches on. -
Page 18: Freezer Compartment
en Freezer compartment Correct setting Freezer compartment 11 Freezer compartment You can store frozen food, freeze Freezer compartment food and make ice cubes in the freezer compartment. The temperature in the freezer com- partment depends on the temperat- 11.2 Freezing capacity ure in the refrigerator compartment. Long-term storage of food should be The freezing capacity indicates the at –18 °C or lower. -
Page 19: Shelf Life Of Frozen Food At −18 °C
Defrosting en ¡ Cooked food is more suitable than 11.6 Defrosting methods for food that can be eaten raw. frozen food ¡ Vegetables: Wash, chop up and blanch before freezing. CAUTION ¡ Fruit: Wash, pit and perhaps peel, Risk of harm to health! possibly add sugar or ascorbic During the thawing process, bacteria acid solution. -
Page 20: Defrosting In The Freezer Compartment
en Cleaning and servicing 12.2 Defrosting in the freezer Cleaning and servicing 13 Cleaning and servi- compartment cing The freezer compartment does not To keep your appliance working effi- defrost automatically. A layer of hoar- Cleaning and servicing ciently for a long time, it is important frost in the freezer compartment im- to clean and maintain it carefully. -
Page 21: Cleaning The Condensation Channel And Drainage Hole
Cleaning and servicing en Liquid in the lighting or in the con- 13.3 Cleaning the condensa- trols can be dangerous. tion channel and drain- The rinsing water must not drip ▶ age hole into the lighting or controls. Regularly clean the condensation ATTENTION! channel and drainage hole to ensure Unsuitable cleaning products may... -
Page 22: Removing Appliance Components
en Cleaning and servicing Lift the fruit and vegetable con- Removing the extendable shelf tainer at the front and remove it Pull out the extendable shelf until . the locking catch is released. Lower the shelf and swing it out to 13.5 Removing appliance the side. - Page 23 Cleaning and servicing en Press the fastenings for the lower glass plate outwards. Lift the glass plate at the front and pull it out at the rear .
-
Page 24: Troubleshooting
en Troubleshooting Troubleshooting 14 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- Troubleshooting ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 25 Troubleshooting en Fault Cause and troubleshooting The base of the refri- The condensation channel or drainage hole are gerator compartment blocked. is wet. Clean the condensation channel and the drainage ▶ hole. → Page 21 The appliance hums, Not a fault. A motor is running, e.g. refrigerating unit, bubbles, buzzes, fan.
-
Page 26: Storage And Disposal
en Storage and disposal 14.1 Power failure Storage and disposal 15 Storage and disposal During a power failure, the temperat- You can find out here how to prepare Storage and disposal ure in the appliance rises; this re- your appliance for storage. You will duces the storage time and the qual- also find out how to dispose of old ity of the frozen food. -
Page 27: Customer Service
Customer Service en Note: Under the terms of the manu- WARNING facturer's warranty applicable to the Risk of fire! location, the use of Customer Service If the tubes are damaged, flammable is free of charge. The minimum dura- refrigerant and harmful gases may tion of the warranty (manufacturer's escape and ignite. - Page 28 en Technical data More information about your model can be found online at https://en- ergylabel.bsh-group.com . This web address is linked to the official EU EPREL product database. At the time of printing its web address had not yet been published. Please then fol- low the instructions on searching for models.
- Page 32 *9001595078* 9001595078 Constructa-Neff Vertriebs-GmbH Carl-Wery-Straße 34 81739 München GERMANY 001105...
