Installation, Start-Up and Service Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . 1,2
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Unit Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
PREINSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18,19
Rigging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Shipping Bolt and Screw Removal . . . . . . . . . . . . . . . . 18
Unit Suspension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Service Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Condensate Drain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
External Vibration Isolators . . . . . . . . . . . . . . . . . . . . . . . 18
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-33
Condensate Drain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Horizontal Bottom Return Economizer
Package (HBREP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Motorized Outside Air Damper . . . . . . . . . . . . . . . . . . . . 22
Mixing Box Actuator (for 39SH and 39SM Horizontal
Return Units Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
• ACTUATOR INSTALLATION
Mixing Box Air Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Mixing Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
(39SH Sizes 00-03)
Install Sheaves on Motor and Fan Shafts . . . . . . . . . 27
Install V-Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
• GENERAL
Coil Freeze-Up Protection. . . . . . . . . . . . . . . . . . . . . . . . . 31
(DX) Coils. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Electric Heaters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Motor Stop/Start Stations . . . . . . . . . . . . . . . . . . . . . . . . . 33
START-UP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Check List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34,35
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Fan Motor Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Coil Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
• DETERGENT
Winter Shutdown (Chilled Water Coil Only) . . . . . . . 34
• PIPING
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53390006-01
Indoor and Outdoor Air Handlers
Page
Printed in U.S.A.
39SH,SV,SM,SR00-17
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Lubrication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
• MOTORS
• BEARINGS
SAFETY CONSIDERATIONS
Air-handling equipment is designed to provide safe and reli-
able service when operated within design specifications. To
avoid injury to personnel and damage to equipment or property
when operating this equipment, use good judgment and follow
safe practices as outlined below.
NEVER enter an enclosed fan cabinet or reach into a unit
while the fan is running.
LOCK OPEN AND TAG the fan motor power disconnect
switch before working on a fan. Take fuses with you and
note removal on tag. Electric shock can cause personal
injury or death.
LOCK OPEN AND TAG the electric heat coil power dis-
connect switch before working on or near heaters.
Failure to follow these warnings could lead to personal
injury or death.
CHECK the assembly and component weights to be
sure that the rigging equipment can handle them safely.
Note also, the centers of gravity and any specific rigging
instructions.
CHECK for adequate ventilation so that fumes will not
migrate through ductwork to occupied spaces when weld-
ing or cutting inside air-handling unit cabinet or plenum.
WHEN STEAM CLEANING COILS be sure that the area
is clear of personnel.
DO NOT attempt to handle access covers and removable
panels on outdoor units when winds are strong or gusting
until you have sufficient help to control them. Make sure
panels are properly secured while repairs are being made to
a unit.
DO NOT remove access panel fasteners until fan is com-
pletely stopped. Pressure developed by a moving fan can
cause excessive force against the panel which can injure
personnel.
DO NOT work on dampers until their operators are
disconnected.
BE SURE that fans are properly grounded before working
on them.
Failure to follow these warnings could result in personal
injury or equipment damage.
Form 39S-2SI
Pg 1
DANGER
WARNING
7-08
Replaces: 39S-1SI
Page
Advertisement
Table of Contents
Related Manuals for Carrier 39SH
Summary of Contents for Carrier 39SH
-
Page 1: Table Of Contents
Mixing Box Actuator (for 39SH and 39SM Horizontal Return Units Only) ......23 LOCK OPEN AND TAG the fan motor power disconnect •... -
Page 2: Introduction
Have a fire extinguisher at hand and ready for immediate use. Failure to follow these warnings could result in personal injury or equipment damage. Table 1 — Physical Data — 39SH Coil and Filter Data 39SH UNIT SIZE CHILLED WATER Nominal Capacity at 400 fpm (cfm) - Page 3 Table 2 — Physical Data — 39SV Coil and Filter Data 39SV UNIT SIZE CHILLED WATER Nominal Capacity at 400 fpm (cfm) 1200 1200 1600 2000 2932 3668 Face Area (sq ft) 7.33 9.17 Coil Connection Size (in. OD sweat) HOT WATER Nominal Capacity at 400 fpm (cfm) 1276...
- Page 4 Table 4 — Physical Data — 39SR Coil and Filter Data 39SR UNIT SIZE CHILLED WATER Nominal Capacity at 400 fpm (cfm) 1224 1612 2000 3252 3792 5124 7000 Face Area (sq ft) 3.06 4.03 8.13 9.48 12.81 17.5 Coil Connection Size (in. OD sweat) 4 Row 6 Row HOT WATER...
- Page 5 †Sizes 13 and 17 are twin blowers. Dimension "E" is to closest blower. Dimension "F" and "G" are typical for both fan outlets. NOTES: 1. Measurements shown in inches. 2. Unit hand is determined by looking into the filters in same direction as airflow. Right hand unit shown for reference. Fig. 1 — 39SH Unit...
- Page 6 a39-4065 4 x 4 J-Box (w/o MSS) 12.5 Top View .875 (OPP SIDE) Power Conn. Motor Start/Stop (MSS) (optional) .875 24V Control Conn. Supply Conn. (CW) Liquid Conn. (DX) Suction (DX)/ Return (CW) Conn. Cond Drain w/ Aux (3/4" FPT) Supply Conn.
- Page 7 31.00 54.0 34.2 Motor Start/ Stop (opt) Supply (CW) / Suction (DX) Conn. 84.4 Return (CW) / Liquid (DX) Conn. 19.5 Drain Conn. 10.1 Supply Conn. (HW) Return Conn. (HW) 20.5 Front View Right View a39-4066 13.3 16.3 20.3 4 x 4 J-Box (w/o MSS) .875 24V Control Conn.
- Page 8 a39-4067 4 x 4 J-BOX (w/o MSS) 12.5 Top View .875 (OPP SIDE) Power Conn. Motor Start/Stop (MSS) (optional) .875 24V Control Conn. Supply Conn. (HW) Return Conn. (HW) Supply Conn. (CW) Liquid Conn. (DX) Suction (DX) /Return (CW) Conn. Cond Drain w/ Aux (3/4"...
- Page 9 MOTOR START/STOP (MSS) 8.18 (OPT) 12.51 .875 POWER ACCESS PANEL CONN. 4X4 J-BOX (W/O MSS) 6.35 CW/HW RETURN AREA FLOW FILTERS CW/HW SUPPLY AREA 3/4" FPT DRAIN REAR VIEW RIGHT VIEW a39-4075 .875 24V CONTROL CONN. .875 (OPP SIDE) POWER CONN. TOP VIEW TOP VIEW SIZES 04-09...
- Page 10 a39-4078 DIMENSIONS (in.) MOTOR COIL BLOWER SUPPLY DUCT SUPPLY RETURN 39SM WIDTH HEIGHT DEPTH START/STOP RETURN DUCT DRAIN SECTION SECTION (BLOWER OPENING) CONN. CONN. UNIT (OPT.) SIZE 40.0 27.5 52.0 27.5 26.0 36.0 25.5 13.6 11.9 13.1 20.0 15.2 40.0 27.5 52.0 27.5...
- Page 11 DIMENSIONS (in.) DUCT DUCT 39SM LENGTH WIDTH HEIGHT FILTERS WIDTH HEIGHT CLEARANCE UNIT SIZE SIZE 04,05 27.0 36.2 25.5 34.3 15.0 16 x 32 x 2 07,09 32.0 48.2 32.4 46.3 15.0 20 x 24 x 2 a39-4079 13,17 40.0 66.2 45.0 64.3...
- Page 12 Pipe Chase Section View "A-A" a39-4068 Right View HORIZONTAL DISCHARGE (OPT) .875 POWER CONN. (4X4 J-BOX) Rear View Front View DIMENSIONS (in.) 39SR UNIT SIZE 02, 03 67.4 39.6 22.5 12.0 25.8 11.9 11.0 35.4 14.2 28.4 15.3 04, 05 72.1 48.1 28.5...
- Page 13 Pipe Chase Section View "A-A" a39-4069 Right View HORIZONTAL DISCHARGE (OPT) L1/L2 Rear View Front View DIMENSIONS (in.) 39SR UNIT SIZE 02, 03 70.0 42.0 30.5 12.0 26.0 11.9 10.0 33.7 17.2 14.2 28.1 16.6 04, 05 74.0 50.5 33.6 12.0 34.0 14.1...
- Page 14 a39-4070 Outdoor Air Hood Return Air Duct DIMENSIONS (in.) 39SR UNIT SIZE 02, 03 30.6 19.9 26.1 26.2 19.9 04, 05 39.9 18.0 25.0 40.0 22.1 Fig. 10 — 39SR Unit Sizes 02-05 — Horizontal Return Economizer Package...
- Page 15 Outdoor Air Return Air DIMENSIONS (in.) 39SR UNIT SIZE 02, 03 32.100 18.940 42.075 17.260 25.950 16.150 04, 05 39.725 22.825 44.025 21.125 27.750 16.250 Fig. 11 — 39SR Unit Sizes 02-05 — Bottom Return Economizer Package...
- Page 16 Outdoor Air Hood Barometric Relief Damper (remove for HBREP conversion) a39-4072 A (HBREP) B (HBREP) LEGEND HBREP — Horizontal Bottom Return Economizer Package DIMENSIONS (in.) 39SR UNIT SIZE 07, 09 13.8 44.1 35.2 34.9 15.4 16.5 48.3 18.8 44.1 39.0 48.6 20.1 20.0...
- Page 17 ACTUATOR (OPT) TRANSFORMER (OPT) REAR ISOMETRIC VIEW FRONT ISOMETRIC VIEW a39-4128 ROTATING DAMPER ASSEMBLY MOAD DIMENSIONS (in.) 39SR UNIT SIZE 02, 03 29.9 19.1 24.1 13.4 10.4 04, 05 37.8 23.5 14.6 25.3 17.3 13.8 07, 09 48.8 28.4 17.4 44.4 21.8 19.6...
-
Page 18: Preinstallation
Fig. 14 — Shipping Bolt and Screw Removal Shipping Bolt and Screw Removal (36SH On 39SH units ensure that all red shipping bolts Unit) — under the unit for support (these support pieces should extend and screws are removed and all other bolts and screws are approximately 1 in. -
Page 19: Installation
VIBRATION ISOLATORS DIFFERENTIAL a39-4081 (FIELD SUPPLIED) DRAIN NIPPLE FAN OFF DIFFERENTIAL TRAP CONDITION WHEN FAN STARTS CEILING – RECOMMENDED COOLING COIL PLATFORM MOUNT DRAIN PAN a39-4125 FAN RUNNING AND CONDENSATE DRAINING Fig. 16 — Condensate Drain INSTALLATION Install a trapped condensate drain Condensate Drain —... - Page 20 b. Take right hood panel and screw in place like g. Place in. x in. gasket on flanges on hood bot- Step a. tom, left hood panel, right hood panel, and top panel that attach to the face of the economizer c.
- Page 21 a39-4094...
-
Page 22: Motorized Outside Air Damper
7. To install barometric hood: a39-4097 For bottom return applications: Take the barometric hood and secure to economizer using screws as shown in Fig. 23. For horizontal return applications: a. Connect field-installed horizontal return ductwork to duct flange. Ensure that bottom return on unit is capped. -
Page 23: Mixing Box Actuator
Fig. 27 — Motorized Outside Air Damper Fig. 31 — Secure Door Panel to Unit a39-4100 Mixing Box Actuator (for 39SH and 39SM Hori- zontal Return Units Only) MIXING BOX ACTUATOR ASSEMBLY (Fig. 32 and 33) — To assemble the mixing box actuator: 1. - Page 24 a39-4105 a39-4107 Fig. 35 — Actuator Installation Side View a39-4108 LINKAGE Fig. 33 — Assembled Actuator LINKAGE ACTUATOR INSTALLATION — To install the actuator: 1. Align actuator so that the actuator linkage arm will have enough clearance for full range of motion. Refer to Fig.
-
Page 25: Mixing Box Air Sensor
3. The mixing box should now hang freely from the unit. NOTE: Hanging brackets (shipped loose), as shown in Fig. 41, are recommended for 39SH and 39SM unit sizes 07 and above. To install brackets, place in approximate Fig. 38 — Mixed Air Sensor Bracket location and use self-drilling screws to attach to mixing box. -
Page 26: Mixing Box Linkage Installation
5. Place a linkage arm onto DR1 and DR2. See Fig. 42 and 43 for proper positioning. Ensure that swivel joints are a39-4116 fully extended to the end of the linkage arm and tighten. 6. Insert linkage rod into swivel joints and tighten. Linkage rod may need to be cut down to size. -
Page 27: Install Sheaves On Motor And Fan Shafts
ACTUATOR LINKAGE Factory-supplied drives are prealigned and tensioned, however, (OPTIONAL) Carrier recommends that the belt tension and alignment be LINKAGE checked before starting the unit. Always check the drive align- ment after adjusting belt tension. When field installing or replacing sheaves, install sheaves on fan shaft and motor shaft for minimum overhang. -
Page 28: Alignment
4. With sheaves aligned, tighten cap screws evenly and 6. To determine correct belt tension, use the deflection progressively. formula given below and the tension data from Fig. 50 as follows: NOTE: There should be a -in. to -in. gap between the mating part hub and the bushing flange. -
Page 29: Water And Steam Coil Piping
Figure 53 illustrates the typical piping at the end of every steam supply main. Omitting this causes many field problems and failed coils. Piping practices are outlined in the Carrier System Design Manual, Part 3, Piping Design. Figure 54 shows the typical field piping of multiple coils. - Page 30 a39-4131 a39-2362tf.tif NOTES: 1. A bypass is necessary around trap and valves when continu- ous operation is necessary. 2. Bypass to be the same size as trap orifice but never less than NOTES: inch. 1. Flange or union is located to facilitate coil removal. 2.
-
Page 31: Coil Freeze-Up Protection
Following the piping diagrams in Fig. 52-56, make all con- expanded into plate fins. The completed assembly includes the nections while observing the following precautions: supply and condensate header and side casings which are built to slant the fin/tube bundle back toward the condensate header. •... -
Page 32: Refrigerant Piping, Direct Expansion
TXVs and close it so that only one TXV is active when the proper refrigerant velocity. compressor is unloaded to its minimum of 33%, we see the Refer to Carrier System Design Manual, Part 3, and size re- following: maining suction line to compressor for a pressure drop equiva- lent to 2.0 F. -
Page 33: Electric Heaters
There are three different options to control tons per circuit when using an unloading compressor. The first is to use CAUTION drop solenoid valve control as illustrated above and let the suction cutoff unloaders “ride” with the load. The second is to Use only copper conductors for field-installed electrical use drop solenoid valve control as illustrated above with wiring. -
Page 34: Start-Up
8. Check vibration. If excessive vibration occurs, check for START-UP the following: Make a walkway inside unit components to Check List — a. Variable sheave (if air balance of system has been protect insulation. Remove all construction debris from unit accomplished: replace sheave with fixed sheave interior. -
Page 35: Air Drying Method Of Coil Protection
ASHRAE Fundamentals Handbook and in the Carrier System Design Guide — Piping 5. Open service valve and circulate solution for 15 minutes; Section, when the entering-air temperature to the coil falls be- then check its strength. - Page 36 CALL FOR FREE CATALOG 1-800-644-5544 [ ] Packaged Service Training [ ] Classroom Service Training Copyright 2008 Carrier Corporation Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Catalog No. 04-53390006-01 Printed in U.S.A.
