- Page 1 Pure Sine Wave DC to AC Power Inverter User Manual MI-5180 Distributed By: Electus Distribution Pty Ltd 320 Victoria Road Rydalmere, NSW 2116 Australia Tel : 1300 738 555 Fax: 1300 738 500 www.electusdistribution.com.au...
-
Page 2: Table Of Contents
Table of Contents A. Introduction B. Application C. Features D. Safety Instructions E. Front View & Main Functions F. Rear View & Main Functions G. Pre-Installation Information H. Electrical Requirements Installation Requirements J. Connection and Testing K. Operation L. Green Power Adjustment M. -
Page 3: Introduction
Pure Sine Wave output with very high quality power, usually with less spikes and surges than grid-supplied power. Please read the entire User Manual carefully before commencing installation. B. Application The MI-5180 Pure Sine Wave Power Inverter will provide 1200 watts of Pure Sine Wave AC power from a 12VDC source. C. Features Capable of driving inductive loads i.e. -
Page 4: Front View & Main Functions
2. Explosive Gas Precautions This equipment contains components that can produce electrical arcs or sparks. To prevent fire or explosion do not install in compartments containing batteries or flammable materials, or in locations that require ignition-protected equipment. This includes any space containing gasoline-powered machinery, fuel tanks, or joints, fittings, or other connections between components of the fuel system. -
Page 5: Pre-Installation Information
1. Ventilation Openings Do not obstruct the ventilation openings; allow at least 25mm for airflow around all openings. 2. Battery terminals Only connect the Inverter to a 12VDC battery, battery bank or other 12VDC power source. (POS+) is Positive, (NEG-) is Negative. -
Page 6: Installation Requirements
I. Installation Requirements 1. Where to install The Power Inverter should be installed in a location that meets the following requirements: • Dry – Do not expose the Inverter to high levels of moisture, rain, snow, spray or bilge fluids. Make sure the Inverter is not exposed to salt water vapour. -
Page 7: Connection And Testing
6. DC Wiring IT IS ESSENTIAL that the battery bank voltage match the DC input voltage rating of the Inverter. Damage to the Inverter could result from improper voltage connections. A Battery Fuse must be installed between the batteries and the Inverter; appropriately sized Motor-Starting fuses or similar are recommended. -
Page 8: Operation
¡ Ï CAUTION! Reversed polarity connections will blow a fuse and may permanently damage the Inverter. Damage caused by a reverse polarity connection is Not covered by warranty. ¡ Ð Step 4: Connect the DC Negative cable to the Negative terminal of the Inverter. Next, connect the DC Negative cable to the Negative (NEG-) terminal on the battery or power source. -
Page 9: Green Power Adjustment
3. Under Voltage Indicator The under voltage indicator indicates that the Inverter has shut down because the protection circuits have sensed the DC input voltage is lower than that recommended for safe operation. 4. Over Temp Indicator The over temp indicator indicates that the Inverter has shut down because the thermal protection circuits have sensed the Inverter has become overheated. - Page 10 2. Over Temperature Shut Down Your inverter will safely provide the output power defined in the technical data section under the conditions specified. If the Inverter shuts down and indicates over temperature, it may be that you have exceeded one of the parameters. Check the following: •...
-
Page 11: Maintenance
WARNING! There are no user serviceable parts inside. Only qualified personnel should carry out maintenance or service the device. Do not open or disassemble the Inverter. Attempting to service the unit yourself may result in a risk of electrical shock or fire. N. -
Page 12: Specifications
O. Specifications Model No. 1200W (L) Continuous Output 1200W Power Output Power 3600W Surge AC Output Voltage 200VAC ~ 240VAC ±1~2% Adjustable Output Voltage Regulation ~ -1.5% to +1.0% Output Frequency 50Hz ± 0.5% Output Wave Pure Sine Wave <2% THD Form Efficiency >70%...
