Warmbier INDE WT5000 User Manual

reliable & caring since 1976
Walking Test Kit, includes:
a WT5000 electrometer, A/D converter with software, hand-held probe, connecting cables, conductive carrying case,
user's instruction in German and English and calibration certificate. The graph of the body voltage measurement will be
displayed „online" on the connected PC or LAPTOP.
Electrometer WT5000:
• Test range: ± 5.000 volts or ± 500 volts
• Accuracy: 5% of measured value
• Input resistance:
• Input capacitance: < 5 pFarad
Part Nr .
7100 .WT5000 .B
WALKING TEST BODY VOLTAGE MEASUREMENT
The UAD1 can be used with the following instruments:
• WT5000 (see above)
• ESVM1000 and ESVM2000 (see page 80)
• includes Data acquisition and analysis software
"Digilloscope" for Windows
WALKING TEST KIT WT5000
> 10 ohm
14
Walking Test Kit - USB-Version
ANALOG/DIGITAL CONVERTER
®
Part Nr .
7100 .UAD1 Analog/Digital converter with USB connector - UAD1
• Display:
• Output:
• Operation:
Includes:
• Electrometer WT5000
• A/D converter UAD1 with USB connector
• Data acquisition and analysis software "Digilloscope"
for Windows
®
• Handheld probe
• Teflon insulated cable
®
• 4 NiMH rechargeable batteries
• Charger
• Conductive carrying case
Body voltage measurement test set-up.
The new software "Digilloscope" can mark the
five highest peaks automatically and calculates the average value.
Logarithmic LED-display
± 500 volts, changeable
to ± 5.000 volts, Peak hold
Analog ± 5 volts for each test range
Rechargeable batteries
(battery charger included)
Complies with IEC 61340-4-5
