AMH-770DSP
AM/FM Stereo Receiver
Scan the QR code to download the AURA Android App.
Scan the QR code to download the AURA IOS App.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMH-770DSP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aura AMH-770DSP

Summary of Contents for Aura AMH-770DSP

  • Page 1 AMH-770DSP AM/FM Stereo Receiver Scan the QR code to download the AURA Android App. Scan the QR code to download the AURA IOS App.

  • Page 2: Installation

    INSTALLATION Preparation The preparation kit is necessary to mount the radio on the dashboard, this kit is available at electronics stores and car audio specialists, check the installation kit before using it to make sure it is the right one for your vehicle. INSTALL THE DEVICE 1.

  • Page 3: Wiring Connections

    WIRING CONNECTIONS WIRING DIAGRAM AMPLIFIER OUTPUT SUBWOOFER(L) SUBWOOFER(R) PRECAUTION +12V DC NEGATIVE EARTH HANDS FREE PUSH TO TALK PUSH-TO-TALK • Allows you to access SIRI or GOOGLE voice via Wireless BT. • Your phone must support SIRI or GOOGLE voice. Once connected to BT, your phone will ask for access to your contact list.

  • Page 4: General Operation

    CONTROL PANEL BUTTONS In power on mode, press the MUTE button to toggle mute ON or OFF. Folder up, button 1 preset Folder down, button 2 preset (repeat), button 3 preset (random), button 4 preset (pause/start), preset station 5 button 11.

  • Page 5: Audio Mode

    FUNCTION •Press the Volume knob and Rotate to select Audio/Display/Tuner/Clock/Beep/ Animation/Demo mode function. Press the Volume knob again to Select desire function mode. AUDIO MODE •Press the Volume knob and Rotate to select SW Level/Manual EQ/Q factor/Preset EQ/Bass boost/Loudness/Subwoofer set/Fader/Balance/X’Over/DTA Setting/Car type. •Long Pless Volume knob to selet 2 way/3 way X’Over mode.
  • Page 6 BALANCE •Press the Volume knob and Rotate to select Balance position. X’OVER •Press the Volume knob and Rotate to select Tweeter/Front HPF/Rear HPF/ Subwoofer LPF. TWEETER •Press the Volume knob and Rotate to select Frequency/Gain left/Gain right. FRONT HPF •Press the Volume knob and Rotate to select Frequency/Gain. REAR HPF •Press the Volume knob and Rotate to select Frequency/Gain.
  • Page 7 SPECTRUM •Press the Volume knob and Rotate to switch ON/OFF. ID3 TAG •Press the Volume knob and Rotate to switch ON/OFF. VERSION •Press the Volume button to check software version. TUNER •Press the Volume button to select Local Seek/Mono Set/Regional/RDS Set. LOCAL SEEK •Press the Volume button to rotate switch ON/OFF.
  • Page 8 Set the clock (CLK) 1. To display the Time press the CLK button. 2. To set the time, press and hold the CLK button and the time will start ashing. 3. Press the button on the front panel or on the remote control to set the time.

  • Page 9: Radio Operation

    GENERAL OPERATION Preset Equalizer (EQ) Press the EQ button on the front panel or on the remote control to switch between EQ, OFF, CLASS, ROCK, POP, FLAT. USB port The USB port on this stereo device is designed for playing media from USB memory devices.

  • Page 10: Usb Operation

    Press and hold the desired preset button (numbered 1-6 on the face of the radio) • for more than 2 seconds to save the station to that preset number. To recall a preset station Select the desired band. • Brie y press a preset button (numbered 1-6) to recall the corresponding preset •...
  • Page 11 EJECT/USB To eject a USB device, press the button to stop playback, then remove the • USB device. Play/Pause Press the (play/pause) button to pause or resume playback Next/Previous Track To play the next track, press the button. • To play the previous track, press the button.

  • Page 12: Auxiliary Input Operation

    To begin pairing, enable BT mode on your mobile phone. 2. When the phone nds this ship/car audio system, the “AURA” name will be displayed. 3. Choose the “AURA” from the device list to pair and connect with this ship/car audio system.

  • Page 13: Remote Control

    Answer a Call When the mobile phone is called, the incoming telephone number displays on • the LCD. To receive the call, press the button on the control panel. • Reject a Call or End a Call To reject or end the call, press the button on the control panel.
  • Page 14 12. RDM (random), preset station 4 button, keypad 4 13. -10 (previous 10 tracks), preset station 5 button, keypad 5 14. +10 (next 10 tracks), preset station 6 button, keypad 6 15. ST (stereo) button, keypad 7 16. LOUD (loudness) button, keypad 8 17.

  • Page 15: Troubleshooting

    TROUBLESHOOTING If you suspect something is wrong, immediately switch power o . Do not use the unit in abnormal condition, for example without sound, or with smoke or foul smell, can cause re or electric shock. Immediately stop using it and call the store where you purchased it.
