Operator's manual for Attachment
Operator's
Operator's
Operator's
Product number:
Please read this manual carefully before using the equipment, and follow all
instructions.
Keep this manual for later reference.
manual for Attachment
manual for Attachment
manual for Attachment
T
i
p
p
i
n
g
t
r
a
T
i
p
p
i
n
g
t
r
a
for 300-700-series loaders:
i
l
e
r
i
l
e
r
A2949
A21200
Tipping trailer 2012 1
Advertisement
Table of Contents
Related Manuals for AVANT A2949
Summary of Contents for AVANT A2949
- Page 1 Operator’s manual for Attachment Operator’s Operator’s manual for Attachment manual for Attachment manual for Attachment Product number: for 300-700-series loaders: A2949 A21200 Please read this manual carefully before using the equipment, and follow all instructions. Keep this manual for later reference.
-
Page 2: Table Of Contents
Tipping trailer 2012 1 CONTENTS Foreword ............................... 3 Designed purpose of use ........................3 Safety instructions for trailers......................... 3 Trailer specifications..........................5 Assembly of the trailer ........................... 7 5.1. Installing the tires ..........................7 Trailer hitch ball ............................7 5.3. Hitching and removing the trailer from the loader ................8 5.4. -
Page 3: Foreword
3(12) 1. Foreword Avant Tecno Oy would like to thank you for your purchase of this AVANT attachment. It has been designed and manufactured on the basis of years of product development and experience. By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure the reliable operation and long service life of the equipment. - Page 4 4(12) • A trailer may tip over, especially when its bed has been lifted. Never leave the driver’s seat when the trailer is tipped. If the material does not slide from the trailer when tipping, lower the bed before trying to assist to empty the trailer with other means. Do not shake or twitch the trailer when it is tipped.
-
Page 5: Trailer Specifications
2,0 – 2,3 bar 2,0 – 2,3 bar Maximum towing speed: 25 km/h 25 km/h Hydraulic function: 2-acting 2-acting Maximum input of 225 bar, 40 l/min 225 bar, 40 l/min hydraulic energy: 200 series Suitable AVANT loader: 500-700 series 400-700 series... - Page 6 6(12) Listed below are the markings and labels fastened to the trailers, which must be visible on the equipment. Replace the warning labels, if they have become unclear or detached completely. New labels are available via your retailer or contact information provided on the cover page. The warning decals contain important safety information.
-
Page 7: Assembly Of The Trailer
7(12) 5. Assembly of the trailer After installing the tires, and towing hitch on model A2949, the trailers are ready to be used. Read the following instructions regarding the assembly and hitching, so that connecting and disconnecting of the trailer can be done safely. -
Page 8: Hitching And Removing The Trailer From The Loader
8(12) If the load applied on the rear axle of the loader is considerably heavier than on the fron axle, the controllability of the loader is hindered. If the extra counterweight kit (180 kg kit) is fitted, the trailer can not be fully loaded. Use only the hitching ball fitting plate A31417. -
Page 9: Connecting And Disconnecting The Hydraulic Couplings
9(12) 5.4. Connecting and disconnecting the hydraulic couplings According to the trailer model, there are either one or two hydraulic hoses. Connect the single hose to the quick coupling of the loader (pressure 1). Check the order of the fittings from the operator’s manual of the loader. -
Page 10: Using The Trailer
Example: Trailer A2949 is filled with soil up to its sides (single sides). The weight of the load is, according to the actual density of the material, in between 0,48 * 1,5 = 0,72 (720 kg) and 0,48 * 1,8 = 0,864 (870 kg). The load carrying capacity must be estimated by taking in account the compactness of the material and the evenness of the load. -
Page 11: Opening And Removing The Sides
11(12) Avoid losing control of the loader or tipping the trailer over by loading the trailer according to operating conditions. On uneven terrains the maximum load carrying capacity may not be achieved, as the controllability of the loader is hindered when a trailer is hitched. -
Page 12: Operating The Rear Hydraulic Outlet Of The Loader
If there are signs of leaking, to check the component, hold up a piece of cardboard in the area where a leak is suspected. Finding any of these faults means that the hydraulic hose or component in question must be replaced. Spare parts are available from your nearest AVANT retailer or service point. -
Page 13: Storage
13(12) Going or reaching under a lifted trailer bed causes hazards of crushing and getting trapped under the lowering trailer bed. The trailer must be lowered completely before any maintenance work. Never go or reach under a tipped trailer. Ejected oil may cause serious injuries. Do not use the equipment if you have discovered a fault in the hydraulic system. -
Page 14: Warranty Terms
Lift cylinder, lower end Lift cylinder, upper end 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) for attachment from the date of purchase. The warranty covers repair costs as follows: • Work costs are covered, if the repair is not performed at the factory. - Page 15 Maschinenrichtlinie (EG-Richtlinie 2006/42/EG mit Änderungen). Die folgende harmonisierte Normen wurden angewandt: SFS-EN ISO 12100-1 -2, SFS-EN 14121-1, SFS-EN 982 Kuvaus: Avant-kuormainten kanssa käytettävä hydraulisesti kippaava perävaunu Beskrivning: Hydrauliskt tippande vagn; arbetsredskap för Avant lastare Description: Hydraulically tipping trailer; attachment for Avant loaders Beschreibung: Hydraulische kippbare Anhänger; Anbaugerät für Avant Radlader...
