TK-STAR MINI GPS
TRACKER
USER MANUAL
PREFACE
Thank you for purchasing the GPS tracker. This manual shows how to operate the
device smoothly and correctly. Make sure to read this manual carefully before using
this product. Please note that specification and information are subject to changes
without prior notice in this manual. Any change will be integrated in the latest release.
The manufacturer assumes not to be responsible for any errors or omissions in this
document.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TK-STAR MINI GPS TRACKER
Summary of Contents for TK-STAR MINI GPS TRACKER
- Page 1 TK-STAR MINI GPS TRACKER USER MANUAL PREFACE Thank you for purchasing the GPS tracker. This manual shows how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. Please note that specification and information are subject to changes without prior notice in this manual.
- Page 2 1. SUMMARY Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. The most advanced technology of GPS and GSM dual positioning. Content Specs. Dim. 47mm x 24mm x 18mm(1.85”*0.94”*0.71”) Weight Network GSM/GPRS...
-
Page 3: Indicator Light Status
INDICATOR LIGHT STATUS MEANING Green light -Solid No GPRS signal Green light -Flash GPRS connection Blue light -Solid No GPS signal Blue light -Flash GPS connection Red light-Solid Charging Red light-off Full charged GSM SIM CARD INSTALLATION GUIDE: Only GSM SIM card works in this model Note: 3.TURN ON THE DEVICE... -
Page 4: Sms Tracking
4.SMS TRACKING 4.1. Call the SIM card phone number in tracker,you will receive a Google Maps link of position, or sending message “G123456#” to SIM card phone number in tracker . E.g: 4.2. Admin number setting (After admin number setting, all SMS operations to the device are under this number only.) Command: admin123456 phone number... - Page 5 E.g： 5. EXPLANATION OF PARAMETERS/CODES IN SMS MESSAGE Pic（1） Pic（2） Pic 1：Replied real-time tracking information under GPS satellites signal. Lat:22.63952 lon:114.17122 Positioning of the latitude and longitude values. Spd：000 This refers to the device moving speed. The unit is km/h. ...
- Page 6 1), Turn on gprs function by sending command “gprs123456” 2),Set apn by sending command “apn123456 content” , “apnuser123456 content” ,“apnpasswd123456 content” pls note the content is from SIM card carrier , there is small blank after 123456 in every command. 6.1.
- Page 7 Set APN password apnpasswd123456 apnpasswd ok xxxx E.g: For tesco mobile SIM card in UK, we got APN information below. APN name:prepay.tesco-mobile.com APN username:tescowap APN password:password Send SMS to set apn below gprs123456 apn123456 prepay.tesco-mobile.com apnuser123456 tescowap (no need to set if without apnuser) apnpasswd123456 password (no need to set if without password) 6.4 Login the app...
- Page 8 Real-time tracking can not only track the position of the device, but also can track the position of smart phone, user can click “+” and “-” to zoom in and zoom out the map. Click“ ” once , APP will show you the latest position；or call the phone number in tracker , you will get the Google link in SMS.
- Page 9 “－” on map (default radius is 100 meters, recommended radius is 500 meters) .Save settings by clicking “OK”. The device will send message when the device is out of the range.
- Page 10 7. Notices: 1.GPS tracking can be worked outdoor. 2.Please make sure GSM SIM card supports making calls, sending messages, GPRS network. 3.Please make sure GSM SIM card is with sufficient balance. 4.Please make sure the GSM card has opened the call shows and turned off the call transfer.
