1. SUMMARY

Working Based on existing GSM/GPRS network and GPS satellites,
this product can locate and monitor any remote targets by SMS or
internet. The most advanced technology of GPS and GSM dual
positioning.

2.Hardware Description

INDICATOR LIGHT STATUS
Yellow light -Solid
Yellow light -Flash
Blue light -Solid
Blue light -Flash
RED-Not lit
RED-Solid red
Note:
GSM SIM CARD INSTALLATION GUIDE:
works in this model
TK-STAR PET GPS TRACKER
USER MANUAL
MEANING
No GPRS signal
GPRS connection
No GPS signal
GPS connection
Fully charged.
Charging.
Only GSM SIM
card

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PET GPS TRACKER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TK-STAR PET GPS TRACKER

  • Page 1 TK-STAR PET GPS TRACKER USER MANUAL 1. SUMMARY Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and monitor any remote targets by SMS or internet. The most advanced technology of GPS and GSM dual positioning.
  • Page 2 3.TURN ON THE DEVICE Once the SIM card has been purchased and credit added,  unscrew the tracker using the screwdriver to remove the 4 small screws in each corner. Then, insert the SIM card into the SIM card holder by push ...
  • Page 3 4.2.EXPLANATION OF PARAMETERS/CODES IN SMS MESSAGE Pic(1) Pic(2) Pic 1 : Replied real-time tracking information under GPS satellites signal. Lat:22.63952 lon:114.17122 Positioning of the latitude  and longitude values. Spd: 000 This refers to the device moving speed. The unit ...
  • Page 4 GPS signal. ♦ Google Link This is the position oflast gps signal appeared. 5.START ONLINE TRACKING PIs activate GPRS by sending command "gprs123456"when the tracker is on,and set APN by following steps. Every sim card carrier has own APN content,we have two methods to find out apn content :check sim card carrier on internet or put sim card into cellphone to find out APN.
  • Page 5 5.3.Turn on GPRS function by sending command "GPRS123456"to the tracker,and set the APN for the tracker,then its online tracking by APP and platform works. (if you did it already in 5.0,no need to set it one more time ) COMMAND INSTRUCTION TOSETAPN INSTRUCTION COMMAND REPLY...
  • Page 6 5.4. Login the app Click the icon "TKSTAR GPS" on desktop and then login the ID and the password of the device (the default password is 123456). User can login by ID or by username, user need to contact reseller to register a username if need to login by username.
  • Page 7 5.6. Historical track playback Historical track could find the route map for nearly six months by choosing the beginning and ending time. 5.7 Geo-fence Click on the upper right corner "+"under main menu for setup geo-fence. Then the device will lock device’s present position as center automatically, then adjust the radius distance by "+", "...
  • Page 8 5.8. Setting: set all parameters of the device Set Admin munber: The phone number that can control the device by SMS, and receive the alarm message. Set SOS number: The number that can receive the alarm message. Low Battery Alarm Switch: Turn on/off the low battery alarm message function.
