TK-STAR TK4000 STICK GPS
TRACKER
USER MANUAL
PREFACE
Thank you for purchasing the GPS tracker. This manual shows how to operate the device: read this manual
carefully before using the device. Please note that specification and information contained in this manual are
subject to change without prior notice. Any change will be integrated into the latest release. The
manufacturer does not accept liability for any errors or omissions that may be contained in this document.
1. SUMMARY
This device combines the latest GPS position and GSM GPRS (mobile communication network) technologies.
The tracker can be operated either by a phone call, by SMS text message, or via the internet (web application,
Android and iOS App).
This product can be directly inserted into USB port in your computer, or directly inserted into another USB port;
1
Advertisement
Related Manuals for TK-STAR TK4000
Summary of Contents for TK-STAR TK4000
-
Page 1: User Manual
TK-STAR TK4000 STICK GPS TRACKER USER MANUAL PREFACE Thank you for purchasing the GPS tracker. This manual shows how to operate the device: read this manual carefully before using the device. Please note that specification and information contained in this manual are subject to change without prior notice. - Page 2 tablet, car, powerbank etc. The tracker can also be used during charging. TECHNICAL SPECIFICATIONS Dimensions 70mm x 25mm x 15mm (2.7"x0.98"x0.60 ") Weight 40 grams Network GSM/GPRS Band 850/900/1800/1900Mhz GPS sensitivity -159dBm GPS accuracy 5 meters Time To First Fix* Cold: 45 seconds | Warm: 35 seconds | Hot status: 1 second Car charger Input: 12—24V | Output: 5V...
- Page 3 Note: insert SIM card before boot, please reboot the device if the SIM card already is installed when the device is on. Insert the SIM card mobile phone card, pay attention to the direction, in accordance with the shell icon. 2.2 TURNING ON THE DEVICE Turn on the unit by pressing the “on/off”...
- Page 4 ** The default password is 123456. If you change it, please replace 123456 in the commands above with the new password. *** Always check the location received has been freshly calculated (GPS signal should be V:A). If the signal status is V:V, it could be that the device has entered Standby Mode. Call the number attached to the device to wake it out of Standby.
- Page 5 Now: lac:253B DD56: The real-time LBS position T:14/11/10 06:08：Timestamp of the time and date when the LBS position was calculated. Bat: 100% The approximate level of the battery. A value between 10% and 100%, with 100% being fully charged.
- Page 6 Search TKSTAR in the Apple App Store/Google Play Store to install the applications on your device. Select “Log in by IMEI” Server: 3.tkstargps.net IMEI: Printed on the back of the device as show in section 3.2.2 and in SMS message Password: 123456...
