- Page 1 F64-USB product manual V1.0 steering wheel for racing simulators Ascher Racing GmbH...
-
Page 2: Table Of Contents
table of contents 1. general information 2. mounting and connection 3. operation 4. configuration tool 5. how to use bite point 6. label application 7. paddle shifter force setting 8. dimensions... -
Page 3: General Information
• package contents: • – F64-USB steering wheel coiled USB cable (Binder connector to USB Type-A) – alternative magnets to adjust paddle shifter force (see foam insert) – bolts and washers to mount standard Quick Release (such as Q1R) –... -
Page 4: Mounting And Connection
USB extension cable mounted securely to the sim rig is recommended • mount Quick Release: 1. SQR wheel side via standard SC2 adapters 2. SQR wheel side via Ascher Racing SQR 70mm Adapter 3. Q1R 70mm wheel side 4. M5 threaded QRs... - Page 5 2.1 SQR wheel side via standard SC2 adapters SQR wheel side SQR 30mm spacer SQR 70mm adapter...
- Page 6 2.2 SQR wheel side via Ascher Racing SQR 70mm Adapter...
- Page 7 2.3 Q1R 70mm wheel side...
- Page 8 2.4 M5 threaded QRs not as straight forward as previous QRs due to both parts being M5 threaded • M5 threads of one part need to be bypassed using captive screws • through hole M5 threaded QRs (e.g. HRS Xero Play QR) bypass the QR part •...
-
Page 9: Operation
3. operation no driver installation required • wheel shows up in Windows as a standard HID-Gamecontroller (human interface device) • configuration tool can be used to adjust settings such as rotary switch modes, master clutch… • refer to the product page to download latest configuration tool/ firmware •... -
Page 10: Configuration Tool
4. configuration tool... - Page 11 4. configuration tool Reset All: reset all settings to factory default Analog Input Mode Throttle and Brake: two separate axis for both clutches • • Dual Clutch: one single axis for both clutches, both signals are compared and whichever signal is greater will be the output 3.
-
Page 12: How To Use Bite Point
how to use bite point recommended procedure for finding suitable bite point setting • enter calibration mode and set bite point to high value, e.g. 80 % pull slave clutch only apply throttle reduce bite point in 1.0 % increments (left joystick) until vehicle starts moving make test starts to fine tune desired bite point setting exit bite point calibration mode recommended procedure for quick race starts... -
Page 13: Label Application
6. label application encoder knobs must be removed to apply label (hex wrench) • to apply labels the easiest way use a tool such as a knife • put the label on the very tip of the knife • position label centered and horizontal •... -
Page 14: Paddle Shifter Force Setting
7. paddle shifter force setting paddle shifter snap action force is set by the combination of magnets and spacers • do not let magnets smash into each other – magnets are very brittle and can break • to pull out installed magnets, put additional magnets carefully on top •... -
Page 15: Dimensions
8. dimensions...
