Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction.
Wood Bag:
1 LC-510-01
1 LC-510-03
1 LC-510-05
1 LC-510-07
1 LC-510-09
1 LC-510-11
4 Leading Edge Stringers
8 Trailing Edge
4 Center Section Sheet
1 Throttle Pushrod
4 Main Spars
2 Center Section Spars
Misc. Parts Loose in Box:
1 Plan Sheet A
1 Instruction Book
2 Main Landing Gear
1 Clear Plastic
Hardware Bag:
1 Left Hand Control Horn
4 Horn Screw
8 Main Landing Gear & Cowl Screw #2x3/8 Sheet Metal Screw
1 Nose Center Brace
2 Wing Bolt Fillers
2 Wing Dowels
4 Strut Wires
2 Landing Gear Straps
COMPLETE KIT PARTS LIST
3/32x4x24 Laser Cut Balsa Sheet
3/32x4x24 Laser Cut Balsa Sheet
3/32x4x24 Laser Cut Balsa Sheet
1/8x4x24 Laser Cut Balsa Sheet
1/16x3x12 Laser Cut Birch Ply Sheet
3mmx6x12 Laser Cut Poplar Ply Sheet 2 Leading Edge
1/8 sq.x24 Balsa Strip
1/16x1x14 Balsa Sheet
1/16x3x18 Balsa Sheet
1/16x12 Wire, Threaded One End
1/8x1/4x24 Balsa Strip
1/4 sq.x3.5 Balsa Strip
7.625
.010x3x6
Small Nylon Control Horn
2-56x3/8 Machine Screw
3/16 sq.x3 Balsa
3/16 Tapered Balsa Wedge
3/16x3/4 Birch Dowels
1/16x1.25 Mild Steel Wire
1/4x3/4 Nylon Strap
1 LC-510-02
3/32x4x24 Laser Cut Balsa Sheet
1 LC-510-04
3/32x4x24 Laser Cut Balsa Sheet
1 LC-510-06
1/8x4x24 Laser Cut Balsa Sheet
1 LC-510-08
1/16x4x12 Laser Cut Balsa Sheet
1 LC-510-10
3mmx6x12 Laser Cut Poplar Ply Sheet
1/4 sq.x24 Balsa Strip
2 Wing Tips
3/4 Balsa Triangle x4.5
2 Trailing Edge
1/16x1x3.5 Balsa Sheet
2 Control Surface Pushrod 1/16x18 Wire, Threaded One End
1 Braces
3/32x3/16x8 Balsa Strip
4 Main Spars
1/8x1/4x13 Balsa Strip
2 Wing Strut
3/32x1/4x12 Balsa Strip
1 Plan Sheet B
1 Decal Sheet
1 Plastic Cowl
1 Right Hand Control Horn Small Nylon Control Horn
1 Elevator Joiner
1/8x3 Birch Dowel
3 Nylon Clevis
Small Nylon Clevis
2 Wing Bolt Plates (F-20) 3/16 Laser Cut Ply
1 Tail Wheel Wire
1/16 dia.x3 Music Wire
2 Wing Bolts
10-32x1 Nylon Bolts
1 Strut Tubes
1/8x2 Plastic Tube
1 Tail Wheel Retainer
Black Nylon Retainer
Advertisement
Related Manuals for Herr Engineering HRR510
Summary of Contents for Herr Engineering HRR510
- Page 1 Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction. COMPLETE KIT PARTS LIST Wood Bag: 1 LC-510-01 3/32x4x24 Laser Cut Balsa Sheet 1 LC-510-02 3/32x4x24 Laser Cut Balsa Sheet 1 LC-510-03 3/32x4x24 Laser Cut Balsa Sheet 1 LC-510-04 3/32x4x24 Laser Cut Balsa Sheet...
- Page 2 The first thing that you need to do is to identify and mark the part numbers on the laser cut parts using the drawings on the following pages as a guide. It is possible that several of the laser cut parts may not be completely cut through. If this is the case you can free the part from the sheet quickly using an X-acto knife.
-
Page 3: Building The Tail Surfaces
Additional Items Required ( Not Included in Kit) Note: These are parts that we have used and are familiar with. There are many other brands available and you may substitute other items that you are more comfortable with or have on hand. 1 Engine .049 to .061 Engine with throttle 1 Radio... -
Page 4: Building The Fuselage
3. Temporarily hinge the elevators to the stabilizer. Do not glue the hinges at this time. 4. Sand the tail surfaces smooth and round all of the edges except the bottom edge of the fin. Building the Fuselage 5. Assemble the fuselages side by gluing parts F-1 and F-2 together. - Page 5 12. Gently squeeze the aft end of the fuselage sides together and hold with two clothes pins or a small clamp. Place the formers F-11 and F-12 into position and glue them to the fuselage sides. Glue the aft end of the fuselage sides together making sure that the joint is straight and not leaning to the left or right.
-
Page 6: Building The Wing
21. Bend and test fit the throttle pushrod into position. Then remove from the fuselage until needed later. 22. Glue one of the F-19 pieces into position. First, apply glue to the lower edge only and attach F-19 to the top edge of the fuselage side. - Page 7 31. Cut the forward top 1/4 sq. main spar to length and glue the two remaining dihedral braces to it as you did the lower spar. Now glue the spar into position. Now glue the two shear webs A into position against the rear of the spars. 32.
- Page 8 38 Glue the top main spar into position. The inboard end should make contact with the top spar in the center section. Glue the 1/4 sq. leading edge into position on the ribs. The outboard end can extend past the last rib and be trimmed later. Glue the top 1/16 x 1 trailing edge into position.
- Page 9 47. Squirt some thin C/A into the 1/8 holes in the F-20 s. Run a 10-32 tap down through the holes to cut the threads for the screws. Put a little more thin C/A onto the threads and then clean them out one last time with the tap. 48.
-
Page 10: Final Assembly
58. Install the motor and mount. Test fit and install the cowl using four #2 sheet metal screws. 59. Cut the plastic windshield to match the pattern on the plan and test fit it to the model. Do not glue into position until after the model is covered. - Page 11 Engineering Corp. reserves the right to change or modify this warranty without notice. In that Herr Engineering Corporation has no control over the assembly or use, no liability shall be assumed or accepted for any damage resulting from the use by the user during construction of the kit or the use of the final user assembled product.
