Herr Engineering AT-6 Texan Assembly Instructions Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction.
1 Plan, Sheet
1 1/16"x12" Landing Gear Wire
5 1/16" sq. x18" Balsa Strip
2 3/32"x1/4"x18" Balsa Strip
1 Instruction Manual
2 Brass Washer
1 3/16" x 60" Rubber Strip
Tools and Building Supplies
You will need the following items to assemble this model. You must read and follow all of the manufactures
instructions provided with these items!
-Glue
-Cutting Tools
-Clear Dope, Thinner & paint brush
-320 and 400 grit sandpaper
-Straight Pins
-Wax Paper
-Needle nose pliers
-1/4" & 1/16" Drill Bit
-Building Board
COMPLETE KIT PARTS LIST
1
Decal Sheet
1
Molded Plastic Canopy
27 3/32" sq. x18" Balsa Strip
1
3/16"x1 3/4" Birch Dowel
1
Molded Plastic Propeller
1
Nylon Propeller Bearing
2
Plastic Wheel Retainers
CA, White Glue, Sigment or Ambroid all work well.
A hobby knife with a #11 blade is used for general cutting. A single edge
razor blade is also a useful cutting tool.
2 Yellow Tissue
1 Molded Plastic Wheel Fairing
2 1/8"sq.x18" Balsa Strip
1 Tail Wheel Assembly
1 Propeller Shaft
2 PlasticWheels
5 Laser Cut Sheets

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-6 Texan and is the answer not in the manual?

Questions and answers

Related Manuals for Herr Engineering AT-6 Texan

Summary of Contents for Herr Engineering AT-6 Texan

  • Page 1 Your kit contains the following parts. Please check your kit for any missing or damaged parts before starting construction. COMPLETE KIT PARTS LIST 1 Plan, Sheet Decal Sheet 2 Yellow Tissue 1 1/16"x12" Landing Gear Wire Molded Plastic Canopy 1 Molded Plastic Wheel Fairing 5 1/16"...
  • Page 2 The first thing that you need to do is to identify and mark the part numbers on the laser cut parts using the drawings on the following pages as a guide. It is possible that several of the laser cut parts may not be completely cut through. If this is the case you can free the part from the sheet quickly using an X-acto knife.

  • Page 3: Building The Tail Surfaces

    Building the Tail Surfaces 1. Always cover the plan with wax paper before building any parts over the plan. This will prevent the parts from sticking to the plan. 2. Build the rudder over the plan using parts R-1 and R-2. The remainder of the structure is made from 3/32" sq. balsa strip as shown on the plan.

  • Page 4: Building The Fuselage

    19. Trim the plastic wheel fairing and test fit it into position. When you are happy with the fit you can glue the plastic fairing into place. Now fit and glue W-11 into position. Set the wing aside until needed later. Building the Fuselage 20.

  • Page 5: Covering The Model

    53. Balance the model at the position shown on the plan. If you plan to fly the model with the landing gear removed then balance the model with the landing gear removed. Your AT-6 Texan is now complete. Safety Rules 1.
  • Page 6 Further Herr Engineering Corp. reserves the right to change or modify this warranty without notice. In that Herr Engineering Corporation has no control over the assembly or use, no liability shall be assumed or accepted for any damage resulting from the use by the user during construction of the kit or the use of the final user assembled product.
