The overall and mounting dimensions are given below. They differ for Cassettes of different
capacities.
1 05 ,4 (4 .1 5")
5 0,8 (2")
8 5,5 (3.3 7 ")
9 3 (3 .66 ")
©1998-1999 CashCode Company Inc
PT# MAN-ST07 Rev.B2 11/99

7. Mounting

5 ,5 (0 .2 2 ")
3 2(1 .26 ")
8 ,25 (.3 2 5 ")
1 96 (7.7 2 ")
1 00 0 B ills
1 44 (5.6 7 ")
6 00 B ills
11 8 (4 .6 5")
4 00 B ills
8 6 (3 .39 ")
1 70 B ills
8 6,7 (3.4 1 ")
The figure «Layout Of Mounting Holes» shows
the template for panel of the external equipment
where the Bill Validator is to be mounted. All the
dimensions are in millimetres and inches (in
parenthesis).
