Assembly
Assembly Procedure
Step 1: Mounting the seat to the seat base.
• Use the 4 x M8 x 20 bolts to fasten the seat to the seat
base.
Step 2: Mount the steering joystick to the steering
shaft.
• Select the steering joystick.
• Slide the joystick into the slot on the top of the
steering shaft, already installed in the steering
column directly in front of the foot pedal controls,
insert the /" bolt into the bottom bolt hole, select
a comfortable operating position, joystick forward
for extra operating room or back for less, once
determined insert the other /" bolt into the upper
hole and tighten both bolts securely.
Step 3: Attaching the left-hand trailer arm to machine
body.
• Locate the trailer arm support axle 30mm in diameter
which extends out on the side of the machine, remove
the circlip from the support axle. Oil machined
portion. Slide the left hand side trailer arm, onto the
axle, replace the circlip, ensuring it is located in the
groove correctly.
Step 4: Attaching dampener strut and right hand
trailer arm.
• Locate the trailer arm support axle 30mm in diameter
which extends out on the right side of the machine,
remove the circlip from the axle. Hold the right side
trailer arm in the vertical position and slide it onto the
axle. Locate dampener strut, remove packing from the
unattached end.
TRU-TURF GR11000C Golf Greens Roller Manual
• Apply Thread lock "Loctite" to the M10 bolt attached
to the dampener strut. Screw the M10 bolt into the
strut support on the trailer arm.
• If necessary use a soft headed hammer and tap the
trailer arm onto the axle until the circlip groove is
revealed, fi t the circlip, ensuring it is located in the
groove correctly.
Step 5: Attaching draw bar to trailer arms.
• Locate the draw bar assembly.
• Gather the ends of the right and left trailer arms.
• Place the drawbar assembly between the trailer arms
and align the holes, ensure the bend is upwards.
• Place one 2/" x /" bolt through each hole, fi t /"
Nyloc nut to each bolt & tighten securely.
• Test to ensure the trailer latch is correctly locking the
trailer arms in the down position. This is important
when trailing the machine. Use the catch locking pin
when transporting the roller, for safety.
Step 6: Attaching wheels to trailer arms.
• Locate the two wheels for the left and right side trailer
arms.
• Check tires for the correct air pressure, approximately
18psi. Do not exceed this pressure. The tires act as the
suspension, hence the low P.S.I.
• Remove wheel nuts from both hubs, slide wheels onto
hub with air valves facing outwards. Replace wheel
nuts and tighten securely.
• Ensure the taper on the nuts, mate into the wheel
tapers correctly.
