Parts List - Tru-Turf GR11000C Manual

Parts List

Part No. Description
E7006 Bush Plain Bronze
E7007 Bush Flanged Bronze
E7010 Washer M10
E7020 Rod End Female M12
E7028 Tube Steering Spacer
E7044 Chain Tensioning Guide
E7045 LED Light
E7050 Drive Chain
E7067 Light Switch
E7131 Sprocker Drive Roller
G7001 Roller; Drive
G7006 Cover, Transmission
G7012 Plate; Serial Number
G7022 Tube & End Caps Assembly Split Roller GR11000C
G7023 Shaft - Split Tube Roller 63.5dia
G7024 Split Roller 63.5dia Assembly
G7025 Bearing - Centre Cap
G7028 Seal Insert - Centre Cap
G7029 Seal Centre - V-Ring V25A
G7030 Washer - Centre Seal Spacer
G7032 Steer Linkage Assembly GR11000C
G7033 Scraper Rod /"
G7035 GR11000C Smoothing Head Assembly
G7036 Body Welded Assembly
G7037 Smoothing Head Welded Assembly
G7038 Tube Tie Rod Steering
G7039 Rod M12 Threaded Steering
R5009 Grip; Hand; Joystick
R5012 Pad; Rubber; Foot Pedal
R5014 Grip; Lever
R5016 Catch; Rubber
R5025B End Cap Black Plastic 35 x 35
R5031 Coupling; Rubber
R5033 Fan
R5039A Bush; Taper Lock
R5046 Rod Unit; Connecting Arm; Foot Pedal to Yoke; Transmission 23, 24
R5049 Spring; Steering Return
R5061 Strap; Mud Flap
R5067 Housing; F205; 4 hole; for R5070 Bearing
R5068 Housing; LFL5J; 2 hole for R5070 Bearing
R5070 Bearing; B5
R5071 Mud Flap
TRU-TURF GR11000C Golf Greens Roller Manual
Page Part No.
31 R5075 Bush; Nylon; Black
31 R5085 Shim 1.0 mm Thick; Honda / Kohler Engine
28 R5087 Key, Woodruff
17 R5089 Key; Woodruff
26 R5094 Spring; Arm; Chain Tensioner
22 R5095 Washer; Capped
16, 33, 34 R5099 Bush; Bronze; for Chain Tensioner Arms
22 R5118 Rod End
16, 33, 34 R5129 Meter; Hour/Tach
28 R5131 Bracket; Transmission; Eaton 11
28 R5132 Arm; Chain Tensioner
14 R5133 Transmission; Eaton 11
14, 35 R5136 Sprocket; 11 Tooth; Duplex
27 R5138 Joiner; Chain; Duplex Eaton 11 Transmission
27 R5139 Coupling; Transmission; Eaton 11
26, 27 R5140 Coupling; Engine; Honda 5.5hp or Kohler 6hp
27 R5141 Sprocket; 27tooth; Duplex; Drive Roller; Eaton 11 Transmission 28
27 R5142 Cushion; Rubber; for Engine Base Plate
27 R5143 Tank; Stainless Steel; Transmission Oil
27 R5144 Breather; Tank; Transmission Oil
17 R5145 Plug; Drain; Tank; Transmission Oil
26 R5147 Cartridge; Filter; Tank; Transmission Oil
26 R5148 Gauge; Sight; Tank; Transmission Oil
14, 25 R5149 Plate; Mounting; Engine
26 R5152 Pipe; Oil
17, 26 R5153 Pipe; Oil
17 R5154 Pipe; Oil
17 R5156 Key; Woodruff ; to suit Eaton 11 Transmission
24 R5159 Rubber Strip; Rest; Trailer
29 R5171 Yoke; Eaton 11 Transmission; to suit Rear Struts
14, 16 R5173 Strut; connects to R5171 Yoke
30 R5178 Pipe; Oil
21 R5184 Rod; Connects Transmission Yoke – Foot Pedal Arm
21 R5195 Key Honda & Kohler Engines
28 R5197 Pad; Rubber Oil Tank
R5202 Gas Strut Body
14, 17 R5203 Strut; End; Bolt Type; M10 Thread
25 R5210 Strut; Kit; 32mm dia. Body
26 R5227 Fitting 90°
28 R5228 Fitting Straight
26, 28 R5229 Fitting 90°
25 R5230 Fitting Straight
Description Page
14, 24, 25
15
28
21
22
22
22
23, 24
16
18, 20, 21, 22
22
18, 20, 21, 22
22
22
21
21
15
18, 19
18, 19
18, 19
18, 19
18, 19
15
18
18
18
17, 21, 22, 24
14
23
23
18
23, 24
21
19
30
30
30
18, 20
18, 19
18, 19
18, 20
36
