Tru-Turf GR11000C Manual page 40

Parts List
Part No. Description
R8132 M8 Ball Fitting Small Flange Zp
R8134 6-6 Rivet
R8149 13mm Retainer Clip
R8150 10mm Retainer Clip
R8153 M8 Cup Fitting 10dia Ball Zp
R8154 M8 Cup Fitting 13dia Ball Zp
R8175 / x Hex Nut UNF Zp
R8189 / x 2/ UNF Hex Bolt
R8208 M8 x 16 Grub Screw Cup Point
R8209 Shield - End Cap 63.5dia
R8210 M8 Ball Fitting 13dia Large Flange Zp
R8212 Bearing - End Cap
R8213 Seal Insert - End Cap
R8214 Seal V-Ring V20A
R8215 Circlip External - Shaft Ends
R8218 12.7 x 25.4 x 1.6 Washer Acetal
R8225 Rubber Dampener Smoothing Head Pivot Bearing
R8227 Slide Upgrade Kit
R8245 / UNF Nyloc NUt
R8250 / UNF Nyloc Nut SS
R8251 / x / SS Spring Washer
R8256 M8 Nyloc Nut Zp
R8270 Wire Loom for Lights
R8274 Seat Frame Welded Assembly
R8275 Seat Base Plate Welded Assembly
R8280 Brake Folded
R8291 Light Kit
R8292 Light Kit with base
R8293 Roll Spring Pin Zp M5 x 24
R8296 Seat Complete with Arm Rests
R8301 Trailer Arm Welded Assembly LH
R8302 Trailer Arm Welded Assembly RH
R8303 Steering Arm Welded Assembly
R8311 Drawbar Welded Assembly
R8312 M6 x 6 Grub Screw Black
R9001 GX200 Engine Honda
R9028 Slide Spacer
T7019 Bearing Brake
TRU-TURF GR11000C Golf Greens Roller Manual
Page
23
21
23
23
23
23
16
19
28
27
23
27
27
27
27
23
26
23
16, 33, 34
26
26
16, 23, 25
16, 33, 34
16, 29
16, 34
29
33
34
22
16
30
30, 31
17
30
26, 28
15
23
29
38
