Waeco ColdMachine 54 Operating Manual

Cooling unit
Hide thumbs Also See for ColdMachine 54:
Table of Contents

Advertisement

Quick Links

54, 55, 84, 85, 86, 87, 94, 95, 96, 97
CS-NC15
DE
13
Kühlaggregat
Bedienungsanleitung
EN
35
Cooling unit
Operating manual
FR
56
Groupe frigorifique
Notice d'utilisation
ES
79
Unidad frigorífica
Instrucciones de uso
IT
101 Gruppo refrigerante
Istruzioni per l'uso
"More information https://www.caravansplus.com.au"
NL
123 Koelaggregaat
Gebruiksaanwijzing
DA
143 Køleaggregat
Betjeningsvejledning
SV
163 Kylaggregat
Bruksanvisning
NO
183 Kjøleaggregat
Bruksanvisning
FI
203 Jäähdytysaggregaatti
Käyttöohje

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ColdMachine 54 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Waeco ColdMachine 54

Summary of Contents for Waeco ColdMachine 54

  • Page 1 54, 55, 84, 85, 86, 87, 94, 95, 96, 97 CS-NC15 Kühlaggregat 123 Koelaggregaat Bedienungsanleitung Gebruiksaanwijzing Cooling unit 143 Køleaggregat Operating manual Betjeningsvejledning Groupe frigorifique 163 Kylaggregat Notice d’utilisation Bruksanvisning Unidad frigorífica 183 Kjøleaggregat Instrucciones de uso Bruksanvisning 101 Gruppo refrigerante 203 Jäähdytysaggregaatti Istruzioni per l’uso Käyttöohje...
  • Page 2 ColdMachine VD-17 Kompressor ein Compressor on Compresseur en fonction Fremdversorgung External Voltage Alimentation Extérieure Speicherabruf Discharge of Cold Accum. Décharge de la Plaque Hauptschalter Main Switch Commutateur principal Temperature Electronic Control “More information https://www.caravansplus.com.au"...
  • Page 3 ColdMachine 3 VD-01, VD-04, VD-08 10 mm 10 mm 10 mm 4 VD-03 5 VD-02, VD-05, VD-18, VD-21 10 mm “More information https://www.caravansplus.com.au"...
  • Page 4 ColdMachine 6 VD-06 VD-07, VD-09 10 mm 8 VD-14N, VD-15 “More information https://www.caravansplus.com.au"...
  • Page 5 ColdMachine 9 VD-16 gn/ge 0 VD-17 “More information https://www.caravansplus.com.au"...
  • Page 6 ColdMachine VD-14N, VD-15 gn/ge “More information https://www.caravansplus.com.au"...
  • Page 7 ColdMachine SW21 SW16 SW19 SW21 “More information https://www.caravansplus.com.au"...
  • Page 8 ColdMachine 2-3 mm SW21 SW16 2-3 mm ∅/mm² 12 V 24 V VD-01, VD-02, VD-03, VD-04, VD-05, VD-07, VD-08, VD-09, VD-18, VD-21 sw/bl gr/ge “More information https://www.caravansplus.com.au"...
  • Page 9 ColdMachine VD-06 sw/bl br gn ws ∨ Blau Braun Grün Grau Schwarz Weiss oder Blue Brown Green Grey Black White Bleu Marron Vert Gris Rouge Noir Blanc Azul Marrón Verde Gris Rojo Negro Blanco o bien Marrone Verde Grigio Rosso Nero Bianco oppure...
  • Page 10 ColdMachine 257 mm 128,50 mm 9,50 mm “More information https://www.caravansplus.com.au"...
  • Page 11 ColdMachine ~ 210 mm “More information https://www.caravansplus.com.au"...

  • Page 12: Table Of Contents

    ColdMachine Notes on using the operating manual Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is to be resold, this operating manual must be handed over to the purchaser along with Contents Notes on using the operating manual .

  • Page 13: Safety Instructions

    1 in figure 2 on page 3. Please observe the following safety instructions. Safety instructions Caution! WAECO International will not be held liable for claims for damage resulting from the following: – Installation errors, – Damage to the device resulting from mechanical influences and overvoltage, –...
  • Page 14 ColdMachine Safety instructions Electronic devices are not toys! Always keep and use the device out of the reach of children. Before you start up the device for the first time, check that the operatingvoltage matches the battery voltage (see type plate). Danger of fatalinjuries! When using the device on boats: if the device is powered by the mains, ensure that the power supply has a residual current...

  • Page 15: Scope Of Delivery

    Accessories If you wish to operate the cooling unit from the 230 V AC mains, please use one of the following rectifiers: Description Item number WAECO rectifier EPS-100W For devices with Bd-35F compressor (50/80/CS series) WAECO rectifier MPS-35 For devices with Bd-35F compressor (50/80/CS series)

  • Page 16: Technical Description

    The cooling units are suitable for use with 12 V or 24 V DC voltage and can therefore be used for camping or on boats. Furthermore, you can connect them to a 230 V mains supply via the WAECO rectifiers (see chapter “Acces- sories” on page 38).

  • Page 17: Installing The Cooling Unit

    Installing the cooling unit ColdMachine Battery monitor The cooling device is equipped with an electronic device to protect against reversing the polarity when connecting to a battery. To protect the battery, the cooling device switches off automatically if the voltage is insufficient (see following table).
  • Page 18 ColdMachine Installing the cooling unit Install a least 10 mm from the wall (not VD-14N and VD-15). Caution! For cooling units without valve couplings (ready-to install units): Do not open the refrigerant circuit during installation. You may have to make the wall openings larger to be able to slide the vaporiser through them (fig.
  • Page 19 Installing the cooling unit ColdMachine No. in fig. a, Explanation page 7 Connection cable No. in fig. j, page 9 and Explanation fig. k, page 10 Connection block Compressor Switch fig. j or TEC controller fig. k Caution! Carefully insulate and seal off the wall openings after installation to prevent moisture penetration.
  • Page 20 ColdMachine Installing the cooling unit Maintain a minimum distance between the condenser and adjoining wall of 50 mm. CS-NC15: Observe the drilling template (fig. l, page 11) and the installation drawing (fig. m, page 12). Installing the external temperature regulator Mechanical thermostat The temperature regulator can be mounted either on the outside or inside of the cooling container.
  • Page 21 Installing the cooling unit ColdMachine If the position in fig. h, page 9 has been reached (2–3 mm distance between both coupling halves), the coupling has not yet been tightened. The coupling only has rubber seals to prevent the loss of coolant. They do not provide long-term protection against leakage.
  • Page 22 ColdMachine Installing the cooling unit Connecting the cooling unit Connecting to a battery The cooling unit can be operated from a 12 V or a 24 V DC voltage supply. Caution! To avoid voltage loss and therefore a drop in performance, the cable should be kept as short as possible and should not be inter- rupted.

  • Page 23: Using The Cooling Unit

    230 V mains supply and the cooling device. Seek advice from a trained technician. ➤ To operate the cooling unit from the 230 V mains, use the WAECO rectifier – EPS-100W for devices with Bd-35F compressor (50/80/CS series), –...
  • Page 24 ColdMachine Using the cooling unit Start the cooling unit Devices without TEC control ➤ Switch in the cooling unit by turning the control button clockwise (fig. 1 A1 or B1, page 3). If you turn the control button further, you can regulate the temperature. De- vices with energy storage function offer a storage activation button (fig.

  • Page 25: Use Coolant Accumulator

    Use coolant accumulator ColdMachine Use coolant accumulator Display and control elements of devices with TEC program control No. in fig. 2, Explanation page 3 Green LED: Indicates that the compressor is working. Yellow LED: indicates that the external power supply is present (voltage is higher than 13.5 V or 27.0 V).

  • Page 26: Guarantee

    Guarantee The statutory warranty period applies. If the product is defective, please return it to the WAECO location in your country (see the back of the instruction manual for the address) or to your dealer. For repair and guarantee processing, please include the following documents when you...

  • Page 27: Disposal

    Disposal ColdMachine Disposal ➤ Place the packaging material in the appropriate recycling waste bins wherever possible. When it comes time to scrap the device, ask your local recycling centre or dealer for details about how to do this in accordance with the applicable disposal regulations.
  • Page 28 ColdMachine Troubleshooting Compressor does not run Fault Possible cause Remedy = 0 V The connection between the battery Establish a connection and the – electronics is interrupted Main switch defective (if installed) Replace the main switch Additional supply line fuse has blown Replace the fuse (if installed) ≤...
  • Page 29 Troubleshooting ColdMachine Cooling capacity drops, interior temperature rises Fault Possible cause Remedy Compressor runs for a Vaporiser is iced over Defrost the vaporiser long time/continuously Ambient temperature too high – Insufficient ventilation and/or cooling Provide improved ventilation for the cooling unit Condenser is dirty Clean the condenser Fan defective (if installed)

  • Page 30: Technical Data

    ColdMachine Technical data Technical data Series 50 CU-54 CU-55 Max. cooling area 130 litres contents: Connection voltage: 12 V DC or 24 V DC Power consumption: 35-40 W, depending on the vaporiser type Dimensions (WxHxD) 386x155x130 220x160x220 in mm: Weight: 6.0 kg 6.5 kg Series 80...
  • Page 31 Technical data ColdMachine Vaporiser VD-01 VD-02 VD-03 VD-04 Max. cooling area 80 litres 30 litres 170 litres 130 litres content at 35 mm PU insulation: Max. cooling area 100 litres 50 litres 200 litres 170 litres content at 50 mm PU insulation: Power consumption: 35 W...
  • Page 32 ColdMachine Technical data Vaporiser VD-16 VD-21 Max. cooling area 130 litres 250 litres content at 60 mm PU insulation: Max. cooling area 200 litres 300 litres content at 100 mm PU insulation: Power consumption: 60 W 60 W Voltage 12 V DC or 24 V DC Dimensions (WxHxD) in 330x260x130 1370x305x10...
  • Page 33 Dometic WAECO International GmbH Hollefeldstraße 63 · D-48282 Emsdetten ℡ +49 (0) 2572 879-195 · +49 (0) 2572 879-322 Mail: info@waeco.de · Internet: www.waeco.de Europe Overseas + Middle East Dometic Austria GmbH WAECO Italcold SRL WAECO Pacific Pty. Ltd. Neudorferstrasse 108 Via dell’Industria, 4/0...
