DA-500 Drive-Alert Installation Manual
2, 6
2, 6
1
1
Cover
1
Introduction to the DA-500 and Accessories
2-3
Quick Installation Guide
4
Operation and Adjustment Instructions
5-7
Using the DA-500 to control chimes, lights, etc.
8
Accessories
9
Frequently Asked Questions
10
Troubleshooting Guide
11
Technical Support and Warranty Information
5 5
3 3
THE BASICS
1
Sensor(s) buried 6-8 inches deep in PVC
detect(s) vehicle(s) entering a monitored area
2
A control panel receives a signal from the
sensor and triggers an alert-whistle inside the
control panel
7 7
MORE OPTIONS
3
Add a remote chime in the front room to alert
those on the first floor
4
Add another chime in the basement to alert
those downstairs
4 4
5
Add a third chime in an upstairs bedroom to
alert those upstairs
6
Add a wireless or hard-wired timer controlled
light kit to turn on outdoor flood lights, indoor
lights and/or lamps to warn strangers or
welcome friends
7
Attach video surveillance to record activity
and display the driveway on a monitor inside
8
Add a repeater to send the signal another 1000
feet to trigger alerts in out buildings, or add a
DA-660 booster-antenna for buildings up to
8/10-mile away from the control panel
9
Activate signs, gates or other equipment
mp0100323
05/2021
Advertisement
Related Manuals for Mier Drive-ALert DA-500
Summary of Contents for Mier Drive-ALert DA-500
- Page 1 DA-500 Drive-Alert Installation Manual THE BASICS Sensor(s) buried 6-8 inches deep in PVC detect(s) vehicle(s) entering a monitored area A control panel receives a signal from the sensor and triggers an alert-whistle inside the control panel MORE OPTIONS 2, 6 2, 6 Add a remote chime in the front room to alert those on the first floor...
- Page 2 Model DA-500 Information and Most Common Accessories DA-500 Kit Drive-Alerts are perfect for use in residential driveways, on farms, at drive-up windows, in remote locations, and to protect valuable assets and equipment such as tractors or construction vehicles. The Drive-Alert will detect a vehicle approaching, or whenever a vehicle or metal equipment is moved.
-
Page 3: Installation
The ideal installation is without any splices. The use of cable other than that which is designed for the Drive-Alert is undesirable and voids the warranty. Improper splices and unsuitable cable are major causes of false alarms. If splicing is unavoidable, splice the cable using Mier’s DA-054 Splice Kit, or equivalent. - Page 4 Installation page 2 of 2 Keep the probe, cable, and control panel at least 8 feet away from heavy power lines, power panels, motors, arcing or sparking machinery, and radio transmitters. In some cases, moving the panel and/or cable a few feet can solve interference problems. FIGURE 1 illustrates the contacts on the bottom of the DA-500 Control Panel, with the sensor correctly attached.
- Page 5 Mier Products has a hard-wired “timer control” accessory available. The DA-505 Timer Control attaches to the Drive-Alert terminals. This Timer Control is adjustable from 45 seconds to 45 minutes. It switches up to one thousand watts of 115 volt power for outside lights. Mier Products also has a hard-wired chime available.
- Page 6 DA-500 Connecting External Hard-Wired DA-655 Chime Note: up to three (3) DA-500 with whistle ON DA-500 with whistle OFF DA-655s can be used with a maximum of fifty RED BLACK SHLD NEG +24DC NO RED BLACK SHLD NEG +24DC NO UN REG UN REG (50) feet of wire)
- Page 7 DA-500 and Remote Hard-Wired DA-505 Timer Control Connection for Hard-Wired Lights DA-500 Whistle Switch MUST be ON Black 16 gauge wire SENSOR Green to #6 NO, normally open 120V Source (10amps max) Red to #5 +24 Volt DC Sensor Wires: Black wires to lights Black to #4 NEG/Ground Red to #1...
- Page 8 DA-500 and Connecting a DA-500LKA for Additional Contacts DA-500 Whistle Switch MUST be ON DA-500LKA SENSOR Red to #6, NO, Normally Open Sensor Wires: Black to #4 NEG/Ground Red to #1 Black to #2 Silver Shield to #3 DA-500 and Connecting the DA-052 Whistle, Bells or DA-091 Power Horns External 24VDC Whistle, Bell or Horn with the DA-500 Whistle Switch ON Note: Limit of two (2) Bells.
- Page 9 • The DA-050 Power Pack is a replacement power-pack/transformer for the Drive-Alerts. If your Drive-Alert accessories do not look like these, you may have older models. Please call Mier’s free tech support line at 800-473-0213 800-473-0213 ~ info@mierproducts.com ~ www.mierproducts.com...
- Page 10 DA-500 Drive-Alert Frequently Asked Questions Q: How many Sensor/Transmitters can be used? A: Three hard-cabled sensors. However there is no way to discriminate which Sensor/Transmitter is causing the alert to sound. Q: How many sound devices can be used? A: See the following list and quantities supported: •DA-063 8 inch Bell QTY 2 •DA-052V Hard-Wired Remote Whistle...
- Page 11 DA-500 Drive-Alert Troubleshooting Tree Step 1 - Check to make sure the Power Light is on. If not, replace the internal 1A fuse, or send to Mier Products for repair. Step 2 - Make sure the sensor is attached correctly and securely to the control panel.
- Page 12 Mier Products, Inc.’s Limited Warranty Program for Drive-Alert Series of Vehicle Detection Systems and Drive-Alert Accessories protects the original owner for one year from the date of purchase against defects in original parts or workmanship. Mier Products, Inc. agrees to repair or replace parts (Mier’s option) that are deemed defective by our Quality Control Team, without charge for parts or labor, if the defective unit is...
