Page 1
SEC/SH/04/21/FZ1 JENNY 2 DRAWER DESK 54479 SSEMBLY NSTRUCTION DO NOT FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
Page 3
SEC/SH/04/21/FZ1 PLEASE CHECK THAT YOU HAVE ALL THE PARTS LISTED BEFORE YOU START PARTS LIST ASSEMBLING. IF YOU DO FIND THAT SOMETHING IS MISSING, DO NOT CONTINUE ASSEMBLY. PLEASE CONTACT YOUR SUPPLIER IMMEDIATELY. HARDWARE ITEM M3.5 x 14mm Screw M4 x 25mm Screw M4 x 32mm Screw Crosshead Screw M6.3 x 40 M5 x 8mm Euro Screw...
Page 4
SEC/SH/04/21/FZ1 STEP 1 STEP 2 STEP 3 oin panel 2, 3 & 4 together using Wood Dowel 8 x 25mm Attach the Drawer Runners 250mm (M3) to panel Use Cam Nut & Cam Bolt (F2) & Wood Dowel 8 x 25mm (D6) and Crosshead Screw m6.3 x 40mm (A17) no.
