CHARLES COMPUTER DESK
ASSEMBLY INSTRUCTIONS
FOR DOMESTIC USE ONLY
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY
YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS
SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH
THE FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE
THIS PRODUCT.ITS USE WILL INVALIDATE ANY CLAIM YOU MAY
HAVE AND COULD MAKE THIS PRODUCT UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECEIVES
IT MAY BE NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME
TO TIME.THIS IS COMPLETELY NORMAL FOR ANY FLAT PACK
FURNITURE.DO NOT OVERTIGHTEN FIXING.
FOR CLEANING,YOU MAY USE A DAMP CLOTH (NOT WET) DO NOT
USE POLISH,DETERGENT OR CHEMICAL CLEANERS.
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT.ALWAYS
USE A PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT
MARKING.
IMPORTANT
PAGE 1 OF 9
SEC/SH/11/16/EU1
Advertisement
Related Manuals for Seconique CHARLES COMPUTER DESK
Summary of Contents for Seconique CHARLES COMPUTER DESK
- Page 1 SEC/SH/11/16/EU1 CHARLES COMPUTER DESK ASSEMBLY INSTRUCTIONS FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
- Page 2 SEC/SH/11/16/EU1 ( SCREWDRIVER NOT PROVIDED ) USE A FLAT HEAD SCREWDRIVER TO TIGHTEN THE CAM NUTS. A QUARTER TURN CLOCKWISE IS ALL THAT IS NEEDED. STEP 1 - PUSH CAM BOLT INTO INSERT STEP 2 - ALIGN THE CAM BOLT WITH THE HOLE AND PUSH TOGETHER UNTIL FLUSH. ( MAKE SURE THE ARROW OF CAM LOCK IS POINTING TOWARD THE HOLE ON EDGE OF PANEL.
-
Page 3: Parts List
SEC/SH/11/16/EU1 PARTS LIST PARTS LIST PLEASE CHECK THAT YOU HAVE ALL THE PARTS LISTED BEFORE YOU START LEFT SIDE PANEL 1 PC ASSEMBLING.IF YOU DO FIND THAT SOMETHING IS MISSING,DO NOT CONTINUE INNER TOP PANEL 1 PC ASSEMBLY,PLEASE CONTACT YOUR SUPPLIER IMMEDIATELY. BASE PANEL 1 PC LOWER BASE CROSSBARS... -
Page 4: Hardware List
SEC/SH/11/16/EU1 HARDWARE LIST DOWEL 6 X 30MM 36 PCS ANTI - TIP STRAP 2 PCS 14 PCS BOLT M6 X 50MM SCREW M4 X 16MM 2 PCS SCREW M4 X 30MM 8 PCS SCREW M4 X 38MM 4 PCS TACK 12 PCS 1 PC HANDLE... -
Page 5: You Will Need
SEC/SH/11/16/EU1 STEP 1 STEP 2 YOU WILL NEED :- YOU WILL NEED :- 4 PCS 4 PCS 1 PC 1 PC SCREW MUST BE INSERTED SCREW MUST BE INSERTED IN THE FIRST IN THE FIRST HOLE ON THE DRAWER HOLE ON THE DRAWER RUNNER. - Page 6 SEC/SH/11/16/EU1 STEP 3 STEP 4.1 YOU WILL NEED :- YOU WILL NEED :- 32 PCS 10 PCS 1 PC STEP 4.2 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE. CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 6 OF 9...
- Page 7 SEC/SH/11/16/EU1 STEP 5.1 STEP 6.1 YOU WILL NEED:- YOU WILL NEED:- 8 PCS 4 PCS 3 SETS 8 PCS 6 PCS 1 PC PLEASE INSERT THE BACK PANEL INTO THE UNIT STEP 6.2 BACK SIDE VIEW 1 & 5 BEFORE FIXING THE TOP PANEL PLEASE ALIGN THE TOP PANEL WITH THE INNER TOP PANEL...
- Page 8 SEC/SH/11/16/EU1 STEP 8 STEP 7.1 YOU WILL NEED:- 13&14 4 PCS 4 PCS 4 PCS 1 PC 2 SETS 13&14 2 PCS 6 PCS 2 PCS STEP 7.2 THIRD HOLE LAST THIRD HOLE FRONT STEP 7.2 BACK STEP 7.4 STEP 7.5 1 X DRAWER THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE.
- Page 9 SEC/SH/11/16/EU1 WARNING HARDWARE LIST Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. ( N ) Anti-Tip Strap - 2 pc s Wall fixings are not supplied with this product as different wall materials require different types of fixing devices.Please make sure you use fixings suitable for the walls in your home.
