In general terms the higher the tower the less obstruction to air flow,
leading to a more effi cient charge capacity. The minimum recommended
tower height is 30ft or 20ft above nearby obstructions as shown below.
2. SPECIFICATION AND PROTECTION
2.1 Specifi cation
Model
Rated speed
Rated power
*Output Voltage
Cut-in wind speed
**Survival wind speed
Rotor diameter
Number of Blades
Blade material
Suggested battery capacity
20 feet (6m)
400 Watt Turbine
28 mph / 12.5 m/s
400 watts
0-15V
6.7 mph / 3 m/s
112 mph / 50 m/s
4 ft / 1.22 m
Plastic steel
>50 A/Hr
3
3
