- Page 1 Circulating pumps Typ S / SF / S-L Operator’s manual / installation instructions Translation of the original...
- Page 2 Im Schelmen 9-11 D-72072 Tübingen / Germany The manufacturer hereby declares that the product: Centrifugal pump type: S, SL, SF (identification numbers: all) Serial number range: 2018000001 - 2023999999 has been manufactured in accordance with the following directives: Directive 2006/42/EC "Machinery"...
- Page 3 The EU Declaration of Incorporation has been issued: Tübingen, 10 April 2018 ---------------------------------------------------- Thomas Merkle Head of Development & Design Schmalenberger GmbH + Co. KG Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany...
-
Page 4: Table Of Contents
Supporting documents for pump operation ............20 Data sheet ......................20 Important Instructions ..................20 Spare parts list and drawings ..........20 Spare parts list ....................21 Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E... -
Page 5: General Details
Coordinate other types of operation with the manufacturer if they are not cited in the User Information documentation or data sheet. This operator’s manual makes it easier to get to Preventing foreseeable misuse know the centrifugal pump and to make full use •... -
Page 6: Safety Instructions
- Prior to starting up, make sure that the opera- sons and the centrifugal pump must be tors have read and understood the operator’s emptied first. manual. Not the operator but the owner is re-... -
Page 7: Transport, Storage, Installation
6 weeks, then the pump housing should be filled with oil (see 2.1.3). Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany... -
Page 8: Installing And Connecting
Installation on an elastic base is recommended if the effect of vibrations (resonance) on the surroundings has to be largely eliminated. Pumps of type "S“ must be installed only in a vertical position. Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany... - Page 9 Note the denomination on the housing: pressure of the pump! S = suction connection, D = pressure To prevent too strong pressure connection surges dampers or blast tanks The pipes must be supported as close as should be installed.
-
Page 10: Pump Operation
German Engineers) regulations must be thermistors are designed according to DIN observed. 44081 and DIN 44082. Compare the available mains voltage with the details on the motor’s factory plate and select the Time relay setting appropriate switching. three-phase motors with... -
Page 11: Operating
To prevent the motor being overloaded, the density must correspond to the data in the specifications. Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany... -
Page 12: Indications Of Faulty Operation
90ºC overall (measured at the exterior of the motor housing). • During centrifugal pump operation the shut- off device in the supply line is not closed. Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E... -
Page 13: Fault Elimination
Replace shaft gasket, change gasket, defective, gasket old, dry running check installation and assembly dimensions Motor wrongly connected Check circuit diagram, see chapter 2.3.5 Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany... - Page 14 / screw (observe impeller gap) Impeller does not press enough on Check installation / assembly mechanical seal dimensions (*) Please consult the manufacturer. Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E...
-
Page 15: Maintenance / Repair
It must be established beyond those of water (which tend to stick or form doubt that the person has studied the operator’s accumulations, for example, or have a high gas manual in detail. - Page 16 3. The rinsing liquid used and any residual fluid out of the pump must be caught and disposed of properly and without placing persons or the environment in any danger. Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E...
- Page 17 - Propyl alcohol and cellulose cloths (no be removed and dismantled as described in cleaning rags!) chapter 4.2.4 . - O-ring lifter - Water and detergent Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany...
-
Page 18: Spare Parts List / Drawing
If this period of time is considerably exceeded the condition of the pump must be checked and, if required, re-conserved. Installation of the mechanical seal Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E... -
Page 19: Disposal
Maintenance / Service must be carried out. For the new re-start the points listed in section 3.1 Initial start-up must also be observed. Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany... -
Page 20: Supporting Documents For Pump Operation
Please also be sure to observe the other Customer service documentation referred to in these operating Schmalenberger provides a 24 hour service for instructions, see chapter 1.2 ! the delivery of spare parts! See our homepage under: Important Instructions www.schmalenberger.de... -
Page 21: Spare Parts List
920/.01 hexagon nut impeller cap nut 932/.01/.02 Retaining ring Not all parts are built into every pump, however. Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany... - Page 22 Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E...
- Page 23 Typ S - L Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany...
- Page 24 Impeller fixation S 2008 S 0012 Spalt = Gap S 0014 Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E...
- Page 25 Filter housing Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany...
- Page 26 Schmalenberger GmbH + Co. KG Pump type S / SF D-72072 Tübingen / Germany Version: 27229 - E...
- Page 27 Pump type S / SF Schmalenberger GmbH + Co. KG Version: 27229 - E D-72072 Tübingen / Germany...
- Page 28 Im Schelmen 9 - 11 Internet: www.schmalenberger.de D-72072 Tübingen / Germany E-Mail: info@schmalenberger.de © 2019 Schmalenberger GmbH + Co. KG ; All rights reserved This document is subject to change without notice Pump Type S / SF Version: 27229 - E...
