- Page 1 ModelAMP-595 300WattStereoAmplifier Owner's Owner's Owner's Owner's Owner's Manual Manual Manual Manual Manual...
-
Page 2: Table Of Contents
INDEX Specifications ...1 Precautions ...2 Installation Instructions ...3 Wiring Instructions ...4 - 5 Stereo and Mixed-Mono Input Wiring Diagram ...6 Stereo and Mixed-Mono Output Wiring Diagram ...7 Mono (Bridged) Input Wiring Diagram ... 8 Mono (Bridged) Output Wiring Diagram ... 9 Operation ...10 - 12 Warranty ...13... -
Page 3: Specifications
10 - 50,000 Hz. ± 1 dB Channel Separation: 50 dB Signal / Noise Ratio: 90 dB (A-Weighted) * Due to continuing improvement, Audiovox reserves the right to change features and design without notice. HELP! 1-800-645-4994 Monday-Friday Saturday Input Impedance:... -
Page 4: Precautions
6. Make certain that the speaker(s) to be used with this amplifier are capable of handling the output power (wattage) of the unit. Use of speaker(s) not rated for the output of this amplifier may cause damage to or failure of the speaker(s) for which Audiovox will not be liable. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Select a mounting area where the amplifier will have sufficient air circulation for proper cooling. Inadequate air circulation will cause the temperature of the amplifier to rise and will trigger the thermal protection mode. 2. Place the amplifier on the mounting surface and mark the locations of the four mounting holes as shown in the illustration. -
Page 6: Wiring Instructions
WIRING INSTRUCTIONS The wiring of your amplifier will depend on the system and speakers you are using but will either be a stereo, mono, or mixed-mono application. The following pages illustrate the input and output wiring for both types. Please refer to the appropriate diagrams for the system configuration you are using. - Page 7 WIRING INSTRUCTIONS 4. Speaker Connections Depending on the type and number of speakers used with the amplifier, wire them to the speaker terminals as per the appropriate wiring diagram. For most applications, #18 gauge wire should be used for the speaker leads but in no case thinner than #20 gauge.
-
Page 8: Stereo And Mixed-Mono Input Wiring Diagram
STEREO AND MIXED-MONO INPUT WIRING DIAGRAM LOW-LEVEL CAR STEREO RCA OUTPUTS RIGHT LEFT IMPORTANT USE EITHER HIGH-LEVEL OR LOW-LEVEL INPUTS, NOT BOTH. RCA TYPE SHIELDED CABLE (NOT INCLUDED) HIGH-LEVEL (SPEAKER) OUTPUTS RIGHT RIGHT LEFT LEFT CHASSISGROUNDONRADIO 5-PIN CONNECTOR USE THIS INPUT WIRING WITH OUTPUT WIRING ON PAGE 7 NOTE: MODE SWITCH ON AMPLIFIER IN STEREO (ST) SETTING FOR... -
Page 9: Stereo And Mixed-Mono Output Wiring Diagram
USE THIS OUTPUT WIRING WITH INPUT WIRING ON PAGE 6 LEFT SPEAKER STEREO MODE : 2 - 8 OHMS MIXED-MONO MODE : 4 - 8 OHMS NOTE: MODE SWITCH ON AMPLIFIER IN STEREO (ST) SETTING FOR THIS WIRING. MIXED-MONO SPEAKER OR SUB-WOOFER WITH CROSSOVER 4-8 OHMS STEREO AND MIXED-MONO OUTPUT WIRING DIAGRAM... -
Page 10: Mono (Bridged) Input Wiring Diagram
MONO (BRIDGED) INPUT WIRING DIAGRAM LOW-LEVEL RCA OUTPUTS TO2nd AMPLIFIER IMPORTANT USE EITHER HIGH OR LOW-LEVEL INPUTS, NOT BOTH. "Y" RCA TYPE SHIELDED CABLE (NOT SUPPLIED) HIGH-LEVEL (SPEAKER) OUTPUTS CAR STEREO CHASSIS GROUND ON RADIO 5-PIN CONNECTOR USETHISINPUTWIRINGWITH OUTPUTWIRINGONPAGE9 TO 2nd AMPLIFIER NOTE: MODE SWITCH ON AMPLIFIER IN MONO (MO) SETTING FOR THIS WIRING. -
Page 11: Mono (Bridged) Output Wiring Diagram
USETHISOUTPUTWIRINGWITH INPUTWIRINGONPAGE8 MONO SPEAKER SUB-WOOFER 4 - 8 OHMS NOTE: MODE SWITCH ON AMPLIFIER IN MONO (MO) SETTING FOR THIS WIRING. MONO (BRIDGED) OUTPUT WIRING DIAGRAM EXISTING SCREW OR BOLT CLEAN PAINT, RUST, DIRT OR GREASE FROM AREA FOR GOOD CONNECTION USE #14 GAUGE WIRE (SEE TEXT) CONNECT THIS... -
Page 12: Operation
OPERATION After initial set-up, the amplifier should not require any further adjustment unless there is a change in the car stereo or speaker system with which it is used. Power Indicator Lamps The Power Indicator Lamps will light to indicate that the unit is connected to the battery and that the Remote Turn-On terminal is receiving +12 volts, thus turning on the amplifier. - Page 13 by the temperature of the unit rising above a safe level or by an overload condition. If activated by a rise in temperature, the unit will resume operation after cooling off to a normal operating range. If activated by an overload condition, the source of the overload must be found and corrected to resume operation of the amplifier.
- Page 14 Cooling Fan This unit incorporates a fan to provide continuous air flow through the unit to keep the heat-sink and components safely within their operating temperature range. The fan is automatically activated whenever +12 volts is supplied to the Remote Turn-On terminal. Fuse The circuitry of the amplifier is protected from damage by an automotive-type fast-blow fuse.
-
Page 15: Warranty
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 16 © 1998 Audiovox Corporation, Hauppauge, N.Y. Printed in Korea 128-5306...
