- Page 1 Model AXTM-600 600 Watt Mono Block MOSFET Amplifier OWNER'S MANUAL...
-
Page 2: Table Of Contents
INDEX Specifications...3 Precautions...4 Installation Instructions... 5 Wiring Instructions... 6 - 7 Input Wiring Diagram... 8 Output Wiring Diagram... 9 Operation... 10 - 11 Warranty...12... -
Page 3: Specifications
High-Level 100 Ohms Input Sensitivity: Low-Level 200 mV - 8 V High-Level 2V - 10 V * Due to continuing improvement, Audiovox reserves the right to change features and design without notice. HELP! 1-800-645-4994 Monday-Friday 8:30am - 7:00pm Eastern Saturday... -
Page 4: Precautions
6. Make certain that the speaker(s) to be used with this amplifier are capable of handing the output power (wattage) of the unit. Use of speaker(s) not rated for the output of this amplifier may cause damage to or failure of the speaker(s) for which Audiovox will not be liable. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Select a mounting area where the amplifier will have sufficient air circulation for proper cooling. Inadequate air circulation will cause the temperature of the amplifier to rise and will trigger the thermal protection mode. 2. Place the amplifier on the mounting surface and mark the locations of the four mounting holes as shown in the illustration. -
Page 6: Wiring Instructions
WIRING INSTRUCTIONS The wiring of your amplifier will depend on the system and speakers you are using but will either be a stereo, mono, or mixed-mono application. The following pages illustrate the input and output wiring for these types. please refer to the appropriate diagrams for the system configuration you are using. - Page 7 WIRING INSTRUCTIONS 4. Speaker Connections Depending on the type and number of speakers used with the amplifier, wire them to the speaker terminals as per the appropriate wiring diagram. For most applications, #16 gauge wire should be used for the speaker leads but in no case thinner than #18 gauge.
-
Page 8: Input Wiring Diagram
INPUT WIRING DIAGRAM CAR STEREO Gray Brown Black Green White HIGH-LEVEL (SPEAKER) INPUT USE EITHER HIGH-LEVEL OR LOW-LEVEL INPUT, NOT BOTH. (WIRE SIDEVIEW) HI-INPUT HI-INPUT Left Speaker Right Speaker RCA TYPE SHIELDED EXTENSION CABLES (NOT INCLUDED) IMPORTANT LOW-LEVEL INPUT X-OVER X-OVER FULL FULL... -
Page 9: Output Wiring Diagram
EXISTING SCREW OR BOLT CLEAN PAINT, RUST, DIRT OR GREASE FROM AREA FOR GOOD CONNECTION. SPEAKER SPEAKER2(MONO) 2-8 OHM GROUND CAR STEREO BATTERY FOR 12 VOLT USE ONLY AUTO-ANTENNA LEAD OUTPUT WIRING DIAGRAM GROUND METAL SECTION OF VEHICLE FUSE FUSE BATT USE #10 GAUGE WIRE (SEE TEXT) -
Page 10: Operation
OPERATION HI-INPUT HI-INPUT X-OVER X-OVER FULL FULL 18dB 18dB 50Hz 50Hz 250Hz 250Hz GAIN GAIN BASS BASS BOOST BOOST After initial set-up, the amplifier should not require any further adjustment unless there is a change in the car stereo or speaker system with which it is used. Power Indicator Lamps The Power Indicator Lamps will light to indicate that the unit is connected to the battery and that the Remote... - Page 11 If, however, there is still output from the amplifier when the car stereo volume control is at its minimum setting, or the output level increases too fast with a small rotation of the volume control, adjust the Level control to decrease the output from the system. Once the correct setting is found, these controls should not require any further adjustment.
-
Page 12: Warranty
AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 90 days from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 13 2003 Audiovox Electronics Corporation, Hauppauge, N.Y. Printed in Korea 128-6558...
