Riverside Furniture Sophie King Bed Assembly Instructions

email: info@riverside-furniture.com
Headboard Panel
H-A
Queen Footboard
F-A
1 pc.

Bed Rail

Bed Rail
R-A
50380 6/0-6/6 Panel Headboard
50381 6/0-6/6 Panel Footboard
50382 6/0 Panel Bed Rails
50372 5/0-6/6 PANEL BED RAILS
Sophie
King Bed
Assembly Instructions

Hardware and Parts packed with the Headboard

1 pc.

Hardware and Parts packed with the Footboard

6/0-6/6 Wood Slat Slat Support Leg
77" Long 7-3/4" long
with leveler
F-B F-C
4 pcs.

Hardware and Parts packed with the Bed Rails

5/16-18 x 1" Long
∅
Allen Head Bolt
R-B
10 pcs.
5/16-18 Hex Nut
2 pcs.
R-F
6 pcs.
#8 x 1" Wood Screw
F-D
8 pcs.
5/16-18 x 1-3/4" Long
∅
M5/16" Spring
Allen Head Bolt
Washer
R-C R-D
2 pcs.
12mm Open
5mm Allen
Wrench Wrench
R-G 1 pc.
R-H
Page 1 of 4
Made in Viet Nam
8 pcs.
M5/16" x 16*2mm
Flat Washer
R-E
18 pcs.
1 pc.
18 pcs.
