DIP switches 1-4:
These four switches select which MIDI channel (1-16) the JX44 will respond to. The guide below shows which position
each switch should be in for each corresponding channel.
DIP SWITCH #
Midi Ch 1
Midi Ch 2
Midi Ch 3
Midi Ch 4
Midi Ch 5
Midi Ch 6
Midi Ch 7
Midi Ch 8
Midi Ch 9
Midi Ch 10
Midi Ch 11
Midi Ch 12
Midi Ch 13
Midi Ch 14
Midi Ch 15
Midi Ch 16
DIP switch 5:
This switch is used to select OMNI mode. OMNI Mode allows the JX44 to respond to Control and Program changes on
any MIDI channel (1-16). Setting the JX44 to a specific channel is particularly useful when linking multiple MIDI devices
as they can all be set to only respond to changes on their assigned channel.
Some MIDI equipment will default to OMNI mode when first switched on, so it is important to check configurations upon
power-up and re-select the channel on your device if necessary.
When in the DOWN position, OMNI mode is OFF and the JX44
will only respond to MIDI messages on the channel selected
with switches 1-4. When in the UP position, OMNI mode is ON
and the JX44 will respond to MIDI messages sent on all MIDI
channels.
DIP switches 6-7:
The JX44 features can be activated using MIDI Control
Changes, Program Changes, or both. Switches 6 and 7 select
how the JX44 will respond to these messages. If both switches
are in the same position the JX44 will respond to both Control
Changes and Program Changes.
DIP switch 8:
Dip switch 8 is used to toggle between two modes of operation
for the stereo EFX Loop. When switch 8 is in the default UP
position, the JX44 is in 'normal' mode. When switch 8 is moved
to the DOWN position, 'wet/dry/wet' mode is activated. Please
see page 8 of this manual for further details on this feature.
Radial Engineering Ltd.
1 2
DOWN DOWN
DOWN DOWN
DOWN DOWN
DOWN DOWN
DOWN UP
DOWN UP
DOWN UP
DOWN UP
UP DOWN
UP DOWN
UP DOWN
UP DOWN
UP UP
UP UP
UP UP
UP UP
3 4
DOWN DOWN
DOWN UP
UP DOWN
UP UP
DOWN DOWN
DOWN UP
UP DOWN
UP UP
DOWN DOWN
DOWN UP
UP DOWN
UP UP
DOWN DOWN
DOWN UP
UP DOWN
UP UP
1 2 3 4 5 6 7
Select OMNI mode by setting DIP
switch #5 in the UP position
DIP # 6
Enable Control Changes DOWN
Enable Program Changes UP
Enable Program Changes UP
and Control Changes
Enable Program Changes DOWN
and Control Changes
JX44 V2™ Owner's Manual
8
7
UP
DOWN
UP
DOWN
