- Page 1 MADE IN GERMANY Instruction Manual Indoor Air Laundry Dryers WT 230 WT 240 WT 250 WT 280...
- Page 2 This instruction manual shall not be reproduced, copied and distributed, neither in parts nor completely, without the manufacturer's written permit. All rights reserved. The instruction manual is based on the technical and product-specific parameters. The manufacturer reserves the right to add supplementary information to the instruction manual.
-
Page 3: Table Of Contents
CONTENTS Notes on this instruction manual ____________________________________________ 2 Target groups ______________________________________________________________ 2 Conventions _______________________________________________________________ 2 Designated use ____________________________________________________________ 3 Safety ____________________________________________________________________________ 3 Safety devices ______________________________________________________________ 3 Hazards from accessories __________________________________________________ 3 Authorized operator _______________________________________________________ 4 User _______________________________________________________________________ 4 Safety instructions _________________________________________________________ 4 Construction ____________________________________________________________________ 5 Transport and installation ____________________________________________________ 6 Transport __________________________________________________________________ 6... -
Page 4: Notes On This Instruction Manual
Target groups This instruction manual addresses the users and operators of the devices manufactured by AERIAL. They must have read and understood the instruction manual. The physical and psychological preconditions for proper and safety-conscious handling of the devices must always be guaranteed. -
Page 5: Designated Use
In this box you find tips and information concerning the use of the device. Designated use The indoor air laundry dryers WT 230/240/250/280 are intended for air dehumidification and laundry drying in closed rooms. The indoor air laundry dryers are designed exclusively for use at atmospheric pressure. -
Page 6: Authorized Operator
SAFETY Authorized operator Indoor air laundry dryers may only be operated by persons commissioned and instructed by the user. In the working area the operator is responsible to third parties. For all activities on the device the responsibilities must be clearly defined and observed. Unclear competencies are a safety risk. -
Page 7: Construction
CONSTRUCTION Original spare parts or spare parts approved by the manufacturer shall exclusively be used. Construction Fig. 1: AERIAL WT series - overview Air intake area with air filter Condensate drain pipe Operating panel On / Off switch Air outlet with two baffle... -
Page 8: Transport And Installation
TRANSPORT AND INSTALLATION Transport and installation Transport Danger to life due to electric shock Touching live parts can lead to death. DANGER Switch off the indoor air laundry dryer via the on/off switch and disconnect the mains plug from the socket outlet before moving the device. -
Page 9: Scope Of Delivery
Operating conditions Series WT 230/240/250/280 indoor air laundry dryers are suitable for use in residential buildings, cellars, garages, water works and storage rooms. They work without problems in the temperature range from +5 to +32 °C and at a relative humidity in the range from 40% to 99%. -
Page 10: Erection And Installation
TRANSPORT AND INSTALLATION Erection and installation The series WT 230/240/250/280 indoor air laundry dryers are designed for stationary use and wall mounting. The indoor air laundry dryer may only be used for the purpose of air dehumidification and laundry drying.. - Page 11 TRANSPORT AND INSTALLATION Select place of installation When selecting the place of installation ensure that an outlet for draining off the condensate is available (refer to section "Installation of condensate drain hose“, from page 11onwards). that a suitable plug socket is available (refer to section "Connection“, from page 11 ...
- Page 12 TRANSPORT AND INSTALLATION The scope of delivery includes one wall rail (Fig. 3) and suitable bolts and sound insulation anchors. Danger of loss of stability or dropping from the wall The indoor air laundry dryer is heavy. A fall or uncontrolled WARNING movements may cause serious injuries and material damage.
- Page 13 A slope of 5 cm minimum per metre of hose must be guaranteed. The series WT 230/240/250/280 indoor air laundry dryers are equipped with a drain pipe for connecting a condensate drain hose 15 x 2 mm (page 5, Fig. 1, item 5).
-
Page 14: Operation And Operator Control
OPERATION AND OPERATOR CONTROL Attach the drain hose safely to an outlet. Ensure that the hose is laid with a slope of at least 5 cm per metre of hose from the device. Operation and operator control Danger of injury and damage to appliance Inadmissible ambient conditions and improper operation of the device CAUTION may constitute a risk. -
Page 15: Commissioning
OPERATION AND OPERATOR CONTROL Laundry dryer All laundry dryer programs and the functions of the buttons on the operating panel are described in the section Operator control, page 13. Automatic defrosting During dehumidification ice may build up on the evaporator. The series WT 230/240/250/280 indoor air laundry dryers are equipped with an automatic hot-gas defrosting system. -
Page 16: Operator Control
OPERATION AND OPERATOR CONTROL Operator control Button Press briefly Press for 5 s Display cupboard dry Program P1=46% "cupboard dry" Drying Time-limited drying: 30 min 30 min. iron dry Program P2=58% "iron dry" Drying Time-limited drying: 60 min 60 min. predried Program P3=65%... -
Page 17: Set Language
OPERATION AND OPERATOR CONTROL Set language Button Press briefly Press for 5 s Display Unit Switch off unit switches off Language Open language German selection Language Select language English (DE, FR, IT, EN) Language Save language English selection Set room dehumidification Button Press briefly Display... -
Page 18: Maintenance And Service
MAINTENANCE AND SERVICE Step Button Function Display Unit Switch off unit switches off Calibrating HY Open hygrostat calibration (press for 5 sec.) Calibrating P2 Select program to be calibrated Calibrating P2 Increase calibration value step by step Calibrating P2 Reduce calibration value step by step Saved Save calibration value... - Page 19 MAINTENANCE AND SERVICE Danger of injury by electric shock and risk of material damage The indoor air laundry dryer may only be repaired by trained WARNING specialised staff. Within the warranty period, any work on the dehumidifier shall only be carried out by the manufacturer or persons commissioned by the manufacturer.
-
Page 20: Troubleshooting
TROUBLESHOOTING Troubleshooting If problems arise with the indoor air laundry dryer please check the following points. Should the fault not be located please contact your technical advisor. Danger of injury by electric shock and risk of material damage The indoor air laundry dryer may only be repaired by trained ... -
Page 21: Fault Messages
WARNING manufacturer or personnel authorised by the manufacturer. Fault messages Display Meaning Remedy Error Sensor problem Get in touch with AERIAL Service Error 1 Problem with refrigeration Get in touch with AERIAL circuit Service Room temperature Ambient temperature Adapt room conditions <3°C - >30°C... -
Page 22: Faults
TROUBLESHOOTING Faults Problem Possible cause Remedy Low or no The air filter is severely Clean the filter (page 5, Fig. 1, dehumidifying soiled. Air intake of indoor item 1) or insert a new one. Check performance air laundry dryer is too the filter before each use. -
Page 23: Shutdown, Storage And Disposal
Disposal Please do not dispose of these indoor air laundry dryers with the domestic waste, nor in the countryside. We dispose of these AERIAL indoor air laundry dryers for you, free of charge and environmentally friendly. Please contact us. Alternatively, your local disposal company will dispose of the indoor air laundry dryer in an environmentally friendly manner. -
Page 24: Specifications
RCCB to be installed by user swimming pools Operating conditions + 3 °C to + 32 °C 40% r. h. to 95% r. h. Type Unit WT 230 WT 240 WT 250 WT 280 Air circulation rate cbm/h Power watt... -
Page 25: 10 Ec Declaration Of Conformity
Community who is authorised to compile the technical documents AERIAL GmbH • Systeme zur Manfred Föhlisch Luftbehandlung AERIAL GmbH • Systeme zur Luftbehandlung Oststrasse 148 Oststrasse 148 D - 22844 Norderstedt D - 22844 Norderstedt Description and identification of the machine... - Page 26 EC DECLARATION OF CONFORMITY 2014/30/EU Directive 2014/30/EU of the European Parliament and of the Council of February 26, 2014 on the harmonisation of the laws of the Member States relating to electromagnetic compatibility (revised version) Published in in L 96/79 dated 29-03-2014 Reference to the applied harmonised standards as referred to in Article 7(2): EN ISO 12100:2010-11 Safety of machinery - General principles for design - Risk...
- Page 27 Page 25 of 25...
- Page 28 Dealer stamp: AERIAL GmbH Systeme zur Luftbehandlung Oststrasse 148 · D-22844 Norderstedt Phone 0049 (0) 40 526 879 0 · Telefax 526 879 20 e-mail: info@aerial.de · Internet: www.aerial.de...
