- Page 1 Professional UHF Wireless Systems ATW-A54P UHF Powered Dipole Antennas, 541-567 MHz ATW-A64P UHF Powered Dipole Antennas, 655-681 MHz Installation and Operation...
- Page 2 An internal gain-setting switch permits selection of +10 or +4 dB operation, to compensate for cable losses or other operating conditions. The ATW-A54P and ATW-A64P are designed for particular UHF frequency bands: ATW-A54P: 541-567 MHz (TV channels 25-30) ATW-A64P: 655-681 MHz (TV channels 44-49) The ATW-A54P and ATW-A64P are designed for interior use.
- Page 3 Antenna Mounting The attractive molded housings are easily removable for installation or adjustment. Simply remove the two silver-color screws located at the rear of each housing and gently pull the housing forward, away from the black metal rear plate (Fig. B). For portable or temporary use, install the included AT8667 brackets with BNC connectors and Attach each bracket to an antenna using two small, black...
-
Page 4: Specifications
Then check for power indications at the antennas and proper operation of the overall wireless system. Rear Plate Antenna Type Operating Frequencies ATW-A54P Housing ATW-A64P Mounting Output Impedance Nominal Amplifier Gain...
