- Page 1 7000 Series Professional UHF Wireless Systems ATW-7373 Handheld Condenser Microphone System ATW-7375 UniPak ™ Transmitter System ATW-7376 Handheld Dynamic Microphone System Installation and Operation...
-
Page 2: Receiver Installation
You have joined thousands of other satisfied customers who have chosen our products because of their quality, performance and reliability. This Audio-Technica wireless microphone system is the successful result of years of design and manufacturing experience. This professional wireless system provides a choice of 100 PLL-synthesized UHF frequencies. - Page 3 13 BALANCED AUDIO OUTPUT JACK: XLRM-type connec- tor. A standard 2-conductor shielded cable can be used to connect the receiver output to a balanced microphone level input on a mixer. 14 GROUND LIFT SWITCH: Disconnects the ground pin of the balanced output (13) from ground.
-
Page 4: Transmitter Setup
ATW-T73 Handheld Transmitter Pad The ATW-T73 offers a pad switch which increases the maximum SPL capability of the microphone by 6 dB. The switch is located under the wire-mesh grille near the base of the element. Handheld Transmitter Switch Cover The handheld systems include two switch cover labels that fit into the grooved recess on the bottom of the transmitter’s lower... -
Page 5: System Operation
“normal” range (not set too high or too low). NOTE: With the receiver’s AF Level set at “0,” its balanced out- put voltage will be similar to that of a typical wired microphone. However, the AF Level may need to be adjusted to accommo- date some microphone inputs. -
Page 6: Specifications
ATW-R73 receivers side-by-side in a single 19" rack space. Pair of UHF ground-plane antennas with "-27 thread for mounting to microphone stands, etc. Takes RF cables with BNC connectors, not included. UHF (728-750 MHz) active unity-gain antenna distribution system provides two “1-in, 4-out” RF channels; connects a pair of antennas to as many as four diversity receivers. - Page 7 Audio-Technica 7000 Series UHF Wireless Operating Frequencies 7000 Series Frequency and Channel Designator List Designator Frequency (MHz) 728.125 728.250 728.375 728.500 728.625 728.750 728.875 729.000 729.125 729.250 729.375 729.500 729.625 729.750 729.875 730.000 730.125 730.250 730.375 730.500 730.625 730.750 730.875 731.000 731.125 731.250...
- Page 8 1. Use only fresh alkaline batteries. Do not use “general purpose” (carbon-zinc) batteries. 2. Position the receiver so that it has the fewest possible obstructions between it and the normal location of the transmitter. Line-of-sight is best. 3. The transmitter and the receiver should be as close together as conveniently possible, but no closer together than three feet.
