7. Indicator Descriptions

Indicator
POWER
PON
TEL 1 - TEL 2
LAN 1 - LAN 4
IPTV
INTERNET
AUTH
USB
Status
Green
Green flashing
Amber flashing
Red
Off
Green
Green flashing
Off
Green
Green flashing
Off
Green
Green flashing
Off
Green
Green flashing
Off
Green
Green flashing
Off
Green
Green flashing
Off
Green
Green flashing
Off
ONR is powered on. The LED displays amber first,
then green flashing and turns steady green
ONR is booting up
New firmware downloading
ONR start up has failed
ONR is powered off
ONR has ranged successfully
ONR is ranging
No light source is detected
Call account is registered
Phone call in progress;
Call account registration in progress
Call account is not registered
Ethernet connected/powered device
connected to LAN port
Data activity present (traffic in either direction)
Power off or Ethernet not connected
IPTV IP address and STB detected and operational
No IP address obtained in IPTV interface
No STB detected
Internet service is OK
Active Internet traffic
Internet service is down
ONR is authorized/authenticated
ONR is ranging or synchronizing
ONR is not authorized/authenticated
Device connected to USB port
Traffic activity on the USB connection
No device connected to USB port
