SingTel Optical Network Router Quick Installation Manual page 5

Step 1: Choose Maintenance > FTTH ID Configuration.
Step 2: Input the FTTH ID (Use FTTH ID provided by Singtel).
Step 3: Click Save.
4.3 Connecting Fiber Cable to the ONR.
Connect one end of the fiber
1.
patch cord to the fiber port
on the back of the ONR, and
secure the optical fiber by fitting
it on the holders. Follow the
arrows in the diagram for the
positions of the holders.
a
As the fiber optic cables are made of glass, please do not bend
sharply and ensure the bending diameter is larger than 30mm.
Verify your service later. Refer to section 5 on how to verify your
3.
service.
b
c
Connect the other end of the
2.
patch cord to the fiber
termination point (FTP).
