5.3.1. LA: Specifications
Analog input
Input type
Number of channels
ADC Type
Sampling Rates
Current Range
Accuracy
Typical noise floor @ 10 kS/sec
Crosstalk (20 kS/sec, -1 dBFS @ 1 kHz)
Gain Drift
Offset Drift
Gain Linearity
Input Coupling
Input Impedance
Overvoltage Protection
Overcurrent Protection
Analog input performance
Bandwidth (-3 dB)
Alias-free Bandwidth
Alias Rejection
Delay Through ADC
Oversampling
Additional Specifications
Isolation Voltage
Power Consumption
Input Connectors
Slice Dimensions
Rev: 1614067200
IOLITE® V20-1
IOLITEi-8xLA
Isolated current
8
24-bit oversampled SAR
Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, 100 S/s (software-selectable)
±20 mA
±0.05 % of reading ±10 µA
-100 dB
-121 dB
Typical 10 ppm/K, Max. 40 ppm/K
Typical 5 ppm of range/K, Max. 15 ppm of range/K
< 0.05 %
DC
50 Ω
In+ to In-: 20 V continuous, 30 Vpeak (100 ms)
In+ to In-: 70 mA continuous
0.49 fs
DC to 0.453 fs
-100 dB (all sample rates)
37 / fs
32
1000 Vpeak channel to ground & channel to channel
Typ. 2.8 W, Max. 3.5 W
BNC
128.4 x 127.6 x 30.1 mm
±2 mA
±0.05 % of reading ±2 µA
-100 dB
-128 dB
Terminal block 2 pole
OMNIMATE SL 2.50 / BLF 2.50/180
128.4 x 115.4 x 30.1 mm
