3.2. Connecting IOLITE®
In this chapter, you can see the basic instructions for connecting IOLITE® devices. Advanced
connections are described in the following chapters.
First connect the power supply cable (PS-120-L1B2f) to the PWR IN 2-pin LEMO 1B male connector. Then
connect a standard ethernet cable to the IN connector of BUS 1 on IOLITE-GATE. Finally connect the
other side of the ethernet cable to the LAN port of PC. You can find advanced connections in chapter
3.3.1.4. Connection of
First connect the power supply cable (PS-120-L1B2f) to the PWR IN 2-pin LEMO 1B male connector. Then
connect L1T8f-RJ45-1M cable (LEMO side) to the IN connector of BUS 1 on the IOLITE-R8 back panel.
Finally connect the other side of the L1T8f-RJ45-1M cable (RJ45 side) to the LAN port of PC. You can find
advanced connections in chapter
IOLITE® V20-1
IOLITE-R12.
Connection of IOLITE-R12 standalone device to PC
3.3.2.4. Connection of
Connection of IOLITE-R8 standalone device to PC
IOLITE-R12
IOLITE-R8
IOLITE-R8.
