- Page 1 DOUBLE VISION ® DU L DISPL Y PH SING VOLTMETER a n d AC C E S S O R I E S Operating & Instruction Manual GlobalTestSupply www. .com uality Products Online at: sales@GlobalTestSupp...
-
Page 2: Table Of Contents
DOUBLE VISION ® DU L DISPL Y PH SING VOLTMETER a n d AC C E S S O R I E S Operating & Instruction Manual IMPORTANT SAFETY INFORMATION ........4 GENERAL DESCRIPTION . -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION Read and understand these instructions prior to use. These operating instructions are not a substitute for proper training in the use of this equipment. High voltage systems present serious hazards, including the risk of death or serious injury due to arcing, thermal burns and electrocution. -
Page 4: General Description
GENERAL DESCRIPTION The HD Electric Dual Display Phasing Voltmeter includes a pair of single stick line-to-ground voltmeters that communicate with each other wirelessly. Both units are constructed with high strength molded housings with epoxy encapsulated high voltage resistors, a ground cord and a digital LED display. The high voltage resistors limit the current through the ground cord to a maximum of less than... -
Page 5: Technical Specifications
TECHNICAL SPECIFICATIONS MODEL NUMBER: DDPM-40 ENVIRONMENTAL CONDITIONS • Conditions - Indoor and outdoor use • Altitude - Up to 6,566 ft. (2000M) • Operating Temperature -20°F to +120°F (-29°C to +49°C) • Humidity - 95% to 49°C (non-condensing) • Pollution Degree - PD4 •... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS The DDPM-40 Dual Display Phasing Voltmeter measures DC and AC RMS voltage from 5V to 25kV line-to-ground at 25-1000Hz and up to 43kV line-to-line at 50/60Hz. Press the ON button on both units to turn them on. The initial zero kV indication will be replaced shortly with the display of hollow zeros as a battery saving measure. -
Page 7: Pre-Use Inspection
OPERATING INSTRUCTIONS ontinued Pre-Use Inspection WARNING: Before using the instrument be sure to test and inspect the equipment to ensure that it is functioning properly and is in safe, working condition. Failure to do so may cause serious injury or death and may result in erroneous test measurements. Before making any high voltage measurements, test and inspect the voltmeter/phaser as follows: 1) Make certain the instrument is clean and dry. - Page 8 OPERATING INSTRUCTIONS ontinued When the meters are first applied to voltage, they both measure line- to-ground voltage. This is indicated in the displays by L-G. Once one meter is applied to line-to- ground voltage, it begins to wirelessly search for a second meter. Any DDPM-40 may connect with any other DDPM-40 applied to voltage in the area.
-
Page 9: Test Point Measurements
OPERATING INSTRUCTIONS ontinued Test Point Measurements To activate Test Point mode simply push the ON button again. Test Point mode is indicated by TP in the display. To turn Test Point mode off, simply press the ON button again to continue cycling through functional modes. -
Page 10: Probes And Accessories
PROBES AND ACCESSORIES WARNING: ALWAYS use probes appropriate to your application. NEVER use overhead probes in underground applications. Failure to use the correct probe can result in arcing or electrical contact and may cause serious injury or death. If you are not trained in the particular operation or are not sure about the appropriate probe for your application do not proceed. -
Page 11: Care And Maintenance
CALIBRATION AND MAINTENANCE LOG DATE CALIBRATED BY GlobalTestSupply www. .com uality Products Online at: sales@GlobalTestSupp... - Page 12 CALIBRATION AND MAINTENANCE LOG DATE CALIBRATED BY GlobalTestSupply www. .com uality Products Online at: sales@GlobalTestSupp...
