Global Test Supply Aurora TGZ370 Owner's Manual

CARE AND MAINTENANCE

1
. Keep body face clean, prevent liquid material from getting into slider to destroy electronics.
2.
Face should be cleaned with a clean, dry, lint-free cloth. Lubricate body with a few drops of
clock oil. Acetone and alcohol must not be used.
3.
Keep battery compartment clean and free of corrosion.

TROUBLESHOOTING

PROBLEM/
Every second 5 digits
jump simultaneously
Display cannot count
Display shows 000.00
or IN 00.000
Function buttons not active
Reading error for full
length is ≥ 0.1mm
No display on LCD screen
SOLUTION/
Battery voltage is under 1.45V.
Remove cover and replace battery.
Faulty circuit. Remove battery, after 30 sec.
put battery back into compartment.
Function buttons and sliders signal end may have
shorted out. Remove the cover, put the button springs in
place with rubber covers. Contact must be unobstructed.
Springs or rubber covers may be out of shape due to
excessive pressing. See solution above for tips.
Sensor may have dirt or deposits in it. Remove cover
and slider assembly. Blow off sensor face with clean
pressurized air ≥ 51kg/cm squared), clean with a dry,
lint-free cloth.
1. Poor battery contact.
Check battery compartment, clean if necessary.
2. Battery voltage is under 1.3V.
Replace with correct battery.
www.
Find Quality Products Online at:
6" All Stainless
Electronic Digital Caliper
No. TGZ370
FOR YOUR SAFETY AND CARE OF THIS TOOL,
please read these instructions carefully and retain them for future use.
