Hisense ISDB-T Service Manual page 15

Chassis: mt5658gcej
Table of Contents

Advertisement

6888 board external terminals description:
Terminal description
Terminal
Digital Audio out
XS3
Earphone out/Audio out
XS2
COMPONENT Video input
XS6
AV/COMPONENT Audio input
XS5
HDMI1/MHL input
XS7
HDMI2/ARC input
XS8
HDMI3 input
XS9
LAN
XS12
USB1(2.0)
XS13
USB2(2.0)
XS14
USB3(3.0)
XS15
RF input ( AJ063-F01T1NY-A\Reflow\ROH )
U3
remark
composite
composite
4K@60Hz
4K@60Hz
4K@30Hz
- 15 -
