- Page 1 Installation & Operating Manual Congratulations on Your Choice in Purchasing this Webtrol Pump! Its Quality is unsurpassed in material and workmanship and has been factory tested. WT/WS Series If properly installed, it will give many years of trouble free service.
-
Page 2: Table Of Contents
Examine the components carefully to ensure that no damage has occurred to the liquid end, motor, cable or control box during shipment. Report damage immediately to the shipping carrier or to your dealer. The Webtrol submersible pump should remain in the shipping carton until it is ready to be installed. Do not drop or mishandle the pump prior to installation. -
Page 3: Installation 3
20’ to avoid cable damage. Notice: Webtrol 4” Submersible Pumps are assembled with right hand threads. Hold the pump’s discharge head with a wrench while installing the riser pipe or a check valve. Be sure you do not loosen the discharge in the tube. -
Page 4: Starting Procedure
Install a sanitary well seal or pitless adapter, submersible pump/motor, electrical conduit and surface piping according to local code requirements. SubDrive/Utility Drive Systems Webtrol has added the SubDrive Systems using 3PH motors, and Utility Drive Pressure Tank Systems designed for use with 3 wire motors. Both Systems will deliver water at a Pressure Sensor constant pressure. -
Page 5: Submersible Motor Cooling
Submersible Motor Cooling Flow Inducer Flow Inducer The submersible motor requires a minimum flow of water past the motor to insure proper cooling. Table 1 Discharge Tube Sleeve below shows the minimum flow rates in GPM for vari- ous diameters and motor size. A flow inducer sleeve is If the casing is too small a tube over the motor,... - Page 6 Table 2 Single Phase Motors Two or Three Wire Cable, 60HZ (Service Entrance to Motor-Maximum Cable Length In Feet) Motor Rating 60°C Insulation - AWG Copper Wire Size Volts 0000 1190 1460 1780 2160 2630 3140 3770 1020 1610 2510 3880 4810 5880...
- Page 7 Table 4 (Continued) ranklin Single Phase Motors Single Phase Motor Specifications (60HZ) 3450 RPM Dual Circuit Winding (1) Maximum Locked Rated Input Breaker Element (Resistance Std. Rotor (Full Load) (S.F. Load) Time Or Fuse /Ohms) Type Motor Volts S.F. Fuse Delay Amps Model...
- Page 8 Table 5 (Continued) ranklin Three Phase Motors Three Phase Motor Specifications (60HZ) 3450 RPM Dual Maximum Rated Input Element Circuit Motor Std. (S.F. Load) Time Breaker Model Volts S.F. Line to Line Locked Code Fuse Delay Amps Ohms Rotor Amps Amps Std.
- Page 9 Table 5A aradyne Three Phase Motors Three Phase Motor Specifications (60HZ) 3450 RPM Dual Maximum Element Circuit Rated Input Motor Std. (S.F. Load) Time Breaker Model Volts S.F. Line to Line Locked Code Fuse Delay Amps Ohms Rotor Amps Amps Std.
- Page 10 Single Phase Motors Figure 3 Figure 4 Figure 5 Figure 6 Two Wire-Direct Two Wire-Direct Three Wire Three Wire Connected to Connected to Connected to Connected Pressure Switch Pressure Switch Pressure Switch through Deluxe 115 V Motor 230 V Motor &...
-
Page 11: System Trouble Shooting 11
System Trouble Shooting Motor Does Not Start Cause of Trouble Checking Procedure Correction Action A. No power or incorrect voltage. Using voltmeter check the line terminals. Voltage must Contact power company if voltage is incorrect. be + 10% of rated voltage. B. -
Page 12: Owners Information
Thank You for Purchasing a WT or WS Series 4” Submersible Pump We at Webtrol are constantly working on new products to make your job easier, while making your systems more efficient, reliable and affordable. Your opinion means a lot to us, so please let us know what you think about our 4” Submersible Pump.
