- Page 3 Length 2” (50.8mm) Weight with Batteries 3.5oz (100g) Battery/Qty CR2 X 1 (3V) Pressure Switch Included Mount/Ring Integral Mounting Deck Battery Operating Time 45mins for Dual Operations Bulb Type R2 16mm LED IRB* Voltage Max. Output 120 lumens Focus Preset Control &...
- Page 4 LASER APERTURE LASER LIGHT AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT 635nm <5mW CW LASER 60825- 1: 2007 & AS/NZS 2211 . 1 : 2004 Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007 Complies with FDA performance standards for laser products, dated June 24,2007...
- Page 5 Note: Pressure Switch will only work when the light, the laser or both have been “activated” by pressing their Push Buttons first. Do not over tighten the Cross-bolt Locking Knob as you could cause Note: Always use the Push Buttons to turn off the light/laser FIRST damage to the main body.
- Page 6 Windage/Elevation Adjustment 1. Once the Flashlight/Laser Combo is mounted in position, the Adjustment Screw on the bottom of the Laser becomes the Elevation Adjustment Screw, and the Adjustment Screw on the side of the Laser becomes the Windage Adjustment Screw. Elevation Adjustment: 2.
-
Page 7: Maintenance
Maintenance Maintain the metal surface of the Flashlight and Laser Combo by removing any dirt Replacement or sand with a soft brush to avoid scratching the finish. Parts Store the system in a cool dry place when not in use. Be careful to avoid contact Contact your distributor with acid, alkaline or corrosive chemicals. -
Page 8: Disclaimer And Limitation Of Liability
One Year Limited Warranty Disclaimer and Limitation of Liability This warranty covers defects in materials and workmanship of the product, provided that they Leapers is pleased to offer suggestions of the use of its products, however Leapers neither assumes are purchased from an authorized distributor and purchased and used in the United States. responsibility for any omissions or errors nor assumes liability for any damages that result from the use The warranty lasts for a period of one year from the date of original purchase of the product.
