Features and Specifications:
Wing Span: 240mm (9.5 Inches)
●
Length:
235 (9.25 Inches)
●
Weight RTF: 28.4g (1 Ounce)
●
Functions:
Right/Left Control and Motor
●
Ready to Fly - Fly Almost Anywhere
●
Flies for Over 6 Minutes on a Single Charge!
●
Includes 1 Cell 150mAH Lithium Polymer Battery
●
Recommended for Ages 10 and Older
●
The Rookie is a very small indoor or outdoor radio controlled flying model aircraft. The Rookie is powered by a small electric motor and a
rechargeable Lithium Polymer flight battery. The Rookie's direction is controlled by a magnetic actuator mounted in the tail. Everything is
included for flight except eight AA size Alkaline batteries for the hand-held transmitter.
SECTION 1: PARTS IDENTIFICATION AND REPLACEMENT PARTS
Upon opening the box, double-check that
you have all of the parts listed below:
Rookie with Motor and
●
Propeller
Lithium Polymer
●
Flight Battery
SECTION 2: BECOMING FAMILIAR WITH THE TRANSMITTER/CHARGER
The Rookie contains
small parts that may
pose a choking hazard.
Not for children under
3 years of age.
Part Number
PH009
OPERATING INSTRUCTIONS
AvAILABLE REPLACEMENT PARTS
To order replacement parts, please
contact your local Phase 3 stockist.
Hand-Held
●
Transmitter
Part No. PH109513 - Motor
PH109513 - Motor
●
Part No. PH109511 - Battery
PH109511 - Battery
●
Part No. PH109512 - Aerial
PH109512 - Aerial
●
Part No. PH109514 - Magnet for Rudder (2)
PH109514 - Magnet for Rudder (2)
●
Part No. PH109515 - Propeller (4)
PH109515 - Propeller (4)
●
Part No. PH109516 - Foam Parts (�ing/Body/Fin)
PH109516 - Foam Parts (�ing/Body/Fin)
●
Should you require replacement parts, we recommend
ordering them from your local model shop.
If they do not stock Phase 3 Models products,
please contact your local Phase 3 distributor.
http://www.phase3models.com
The On/Off switch has three different positions. All the way up is the "ON"
position, in the middle is the "CHARGE" position and all the way down
is the "OFF" position.
1
Phase 3 Models,
P.O. Box No. 402, Texaco Road PO,
New Territories,
Hong Kong.
www.phase3models.com
All contents copyright © 2006 Phase 3 Models
Version 1.0 October 2006
