1 SDC Sedona Controller Workbench Installation

1. Introduction

SDC-30 controllers use the open source Sedona framework. The SDC controllers are programmed either

with the dedicated Sedona Workbench or with AX Workbench. The Sedona Workbench is a dedicated

programming tool for Sedona products.

The AX Workbench is a much wider tool used with Niagara Framework products e.g. JACE, Hawk and

TONN. The SDC-30 controllers can be programmed using AX Workbench range products, allowing the

existing AX Workbench users easily integrate the SDC controller programming into the AX Workbench

Suite.

In this application note both stand-alone Sedona Workbench as well as Niagara AX workbench installation is

reviewed.

2. Sedona Workbench Installation

Sedona Workbench is the dedicated tool for programming SDC-30 controllers and SDC-TS touchscreen

devices.

The Sedona workbench is available for downloaded from SyxthSense web-site, or supplied on the Sedona

Workbench CD.

To download from SyxthSense web-site, go to the Support Forum:-

http://www.syxthsense.com/support1.php

To access Support Forum you need to register, and the access rights need to be elevated to Partner level.

After registration please contact

After logging in Search from the Support Menu entry "SDC Sedona Controller Range" and "Software".

From here download the "Sedona Workbench Bundle".

After downloading the zip-file, unzip the file. This creates folder "SDC Customer CD". From this select

subfolder "Sedona Workbench v1.0.47 Software", and run setup.exe. Follow the instructions.

Note. If installing under Windows 7, please make sure to run the setup.exe as "Run As Administrator". To do this "right

mouse click" on the setup.exe and select this option.

Installation creates "Workbench" icon on the desktop. Double-click this to run the Sedona Workbench

software.

Note. Under Windows 7, please make sure that the Sedona Workbench is run as administrator. To do this, search for the

Sedona

installation

folder

./Sedona/SedonaWorkbench-1.0.47/bin/wb_w.exe. To configure, highlight wb_w.exe and select properties, and tick the

box "Run As Administrator". If the software is not run as administrator, the Host ID is changed every time when the

software is run, and the software licensing will not work.

PAGE 1 of 3

File Name: SDC-AN001-WorkbenchInstallation.docx

support@syxthsense.com

and

the

executable

called

SDC Sedona Application Note 001

Sedona/AX Workbench Installation

to change the access right levels.

wb_w.exe.

This

installed

e.g.
