ATN Night Shadow CGTI Specifications

AMERICAN TECHNOLOGIES
NETWORK, CORP.
Night Shadow-CGTI
Night Shadow-CGTI
ATN Night Shadow-CGTI is a Night
Vision Binocular with built in exclusive ATN
Smart Technology. Those night vision
glasses have Proximity Sensor automatically
turns the night vision binoculars ON when it is
brought in the viewing position a feature that
Bushnell and Night Owl night vision do not offer.
The Night Shadow-CGTI features all of the
benefits of Generation 2 technology, such as
automatic brightness and gain control, bright light
protection, along with a powerful IR illuminator. Specialized
multicoated optics provides extreme clarity in low-light
situations. With 5X Magnification and designed for long ranges
is an excellent choice for For Camping, Boating, or Nature
study. There is simply no better commercial Bi-ocular night
vision device on the market.
The Night Shadow-CGTI comes standard with our cutting
edge "Smart" technology. This technology consist of a
proximity sensor, digital controls and a long-range infra-red
illuminator. The proximity sensor will automatically turn the unit
on and off when it is brought to the viewing position. This helps
save your battery life and the life of the unit itself. The digital
controls allow you to activate all of the features of the Night
Shadow with an easy push of a button. We also built a
powerful infra-red illuminator into the scope. This allows you to
see even in total darkness with outstanding clarity.
It is dark. You can barely see your hand in front of your face.
You bring your Night Shadow-CGTI night vision device up to
your eyes and turn it on. Suddenly,in green-hued clarity, the
entire scene is like day. For Camping, Boating or Nature study
there is simply no better commercial Bi-ocular night vision
device on the market.
Total darkness IR............ Standard
Magnification................... 5x
Lens system................... F1:1.7, F90mm
FOV................................. 20
Diopter adjustment.......... -5 to +5
Power supply.................. one 1.5 volt AA size
Range of focus............... 4.5m to infinity
Controls.......................... Digital
Battery life....................... 10-20 hours
Dimensions..................... 225mm X 150mm X 62mm /
9" X 6" X 2.5"
Weight............................. 1.4kg / 3lbs
American Technologies Network Corp.
1341 San Mateo Avenue, South San Francisco, CA 94080
800-910-2862 650-875-0130 FAX 650-875-0129
o
IMAGE INTENSIFIER TUBE QUALITY 2ND GEN
MINIMUM
PHOTO SENSITIVITY
MICRON
EBI
LUMINANCE GAIN
INPUT CURRENT
RESOLUTION
SIGNAL-TO-NOISE RATIO
www.atncorp.com
E-mail: info@atncorp.com, sales@atncorp.com
MAXIMUM UNITS
350 600 MICROAMP/
LUMEN
0.01 0.06 AMPS/WATT
2.5 1.71 Lm/cm2
10000 25000 FL/fcd
0 14 mA
40 21 LP/mm
16 20
