Sekonic SR-450 Operating Manual

Sekonic SR-450 Operating Manual

Optical mark reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SECONIC SR-450 英文表紙  （368mm×257mm）
Operating manual
Head Office : 3-1-3, Ikejiri, Setagaya-ku, Tokyo 154-0001, Japan
Telephone : +81-3-5433-3611 Fax : +81-3-3410-2611
Web Site: https://www.sekonic.co.jp
CM0697510
K
DIC
579

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR-450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sekonic SR-450

Summary of Contents for Sekonic SR-450

  • Page 1 SECONIC SR-450 英文表紙  （368mm×257mm） Operating manual Head Office : 3-1-3, Ikejiri, Setagaya-ku, Tokyo 154-0001, Japan Telephone : +81-3-5433-3611 Fax : +81-3-3410-2611 Web Site: https://www.sekonic.co.jp CM0697510...
  • Page 2 In a residential environment this device may cause radio interference. In this case, the user may be required to take appropriate measures. Notice Microsoft Visual Basic is a registered trademark of Microsoft Corporation. This product must not be reproduced or modified without permission from SEKONIC.
  • Page 3 3. Rights to the Software The copyright and property rights of this software belong to SEKONIC. The user is given the right to use and reuse the software in accordance with this agreement, but does not have the copyright or proper- ty right or any other right to this software.
  • Page 4 In any case, if at any time SEKONIC is deemed responsible, the highest compensation will be the amount paid by the user in damage, cost and legal fees.
  • Page 5 Before Usage Before Usage Make sure that the following are contained in the package immediately after unpacking the product. 1. Main unit 2. Power cord 3. Operation manual 4. Stopper plate 5. Cards 1) 12-line standard-sized check cards 2) 15-line postcard-sized check cards 3) Paper feeding roller protection card 6.
  • Page 6 The scope of this warranty is limited to this product and its accessories. Note that SEKONIC will not be responsible for any financial damage, lost profit or claim from a third party resulting from operation of...
  • Page 7 Safety Precautions Safety Precautions Notice Handling the Device Correctly and Safely Read the "Safety Precautions" carefully before using, and use this product correctly. This "Safety Precautions" page lists various graphical symbols to ensure the safe operation of this product to prevent users, other people or property from being damaged. Thoroughly read these precau- tions and understand the meaning of the symbols before proceeding to the main text of this manual.
  • Page 8 Warning Warning Do not place your hand on the paper feeding surface while the device is in operation. Your hand can be caught and injured due to incorrect usage. Do not place your hand into any moving parts while the device is in operation. Your hand can be caught and injured due to incorrect usage.
  • Page 9 Warning Connect a ground cable and ground the device. Be sure to ground the device with a ground cable. Otherwise, an electric shock may occur. When connecting or disconnecting the ground cable, unplug the power cord first. Otherwise, an electric shock may occur. Warning How to Handle the Device Do not spray organic solvent such as flammable fluids or paint thinner.
  • Page 10 Caution Caution Before moving the device, make sure to unplug the power cord from the outlet. Before moving the device, make sure to unplug the power cord from the outlet. If the power cord is damaged, a fire or an electric shock may occur. Do not install on an unstable surface.

  • Page 11: Table Of Contents

    Table of Contents Table of Contents 1. Precautions on Usage ......................1 2. Names of Each Part ......................3. Specifications ........................4. Installing the USB Driver ....................4-A Before installation ..................... 4-B Installation Procedure ....................4-C Checking the Assigned port ..................4-D Troubleshooting for Communication Errors ............
