- Page 1 10 CSB Corner Subwoofer...
-
Page 2: Table Of Contents
The serial number is found on the back panel. Copyright © 2006 Atlantic Technology International. Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or designs at any time without notice. -
Page 3: Sonnel
Instruction Manual 10 CSB Subwoofer Rear Panel Figure 1 Variable Level Control Use this control to set the level of bass desired Status LED This will be green for "on" condition, amber for "standby" Low Level Input This is the preferred input to connect to the subwoofer or LFE line out from your receiver/processor.(pgs 5 and 6) Low Pass Control... -
Page 4: Features
Sealed enclosure woofer designs are inherently low in distortion,and deliver deep smooth bass response with a gradual and predictable roll-off below resonance.As with all Atlantic Technology subwoofers, we have paid close attention to providing accurate musical bass repro- duction along with terrific special effects. -
Page 5: Connecting Your Subwoofer
Instruction Manual Connecting Your Subwoofer The Atlantic Technology 10 CSB is simple to hook up, offering several connection methods for maximum flexibility.Study the system diagrams starting on the next page.Once you have found the example which most closely matches your system, hook up your subwoofer(s) as shown in that diagram. -
Page 6: Example 1: Subwoofer Line Out/Low Level In
Connections Example 1: Subwoofer Line Out/Low Level In This is the simplest,most common connection. STATUS L/MONO LEVEL RIGHT NORMAL BYPASS LOWPASS Subwoofer AUTO STDBY Example 2: Sub Out/Low Level In, Two Subs 2A. Y-Adapter located at Receiver/Processor INPUT STATUS L/MONO HIGH LEVEL LEVEL... -
Page 7: Example 3: Preamp Line Out/Low Level In For 1 Subwoofer
Instruction Manual Example 3: Preamp Line Out/Low Level In for 1 Subwoofer This arrangement is for owners of stereo receivers/amplifiers with Preamp outputs. STATUS L/MONO LEVEL RIGHT NORMAL BYPASS LOWPASS Subwoofer AUTO STDBY Example 4: Preamp Line Out/ Low Level In for Stereo Subwoofers Note that the L/MONO input is used on both subwoofers. -
Page 8: Example 6: Speaker Out/High Level In For 1 Subwoofer
LEVEL Connections Example 6: Speaker Out/High Level In for 1 Subwoofer FREQ This is the most common method for connecting a subwoofer to a system without a dedicated subwoofer line NORMAL out or preamp outputs.The signal that comes from the High-Level Output jacks is hi-pass filtered to prevent overdriving the satellites with deep bass frequencies. -
Page 9: Sonnel
Instruction Manual Placement Place the subwoofer in the corner of the room flush up against the walls, as shown.You will still obtain perfectly acceptable results even if there is a 2 or 3-inch distance between the subwoofer cabinet and the walls because of decorative baseboard wall molding or other obstruction. -
Page 10: Csb Corner Subwoofer
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLICANCE TO RAIN OR MOISTURE. NO USER SERVICEABLE range (Large) mode.When using a subwoofer with Atlantic Technology PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL speakers we recommend setting such a controller to the Small position for all the speakers in the system,with one exception. -
Page 11: Painting The Cabinet
Instruction Manual Painting the Cabinets The cabinet may be painted to blend in even better with your room’s décor. First,clean the cab- inet,using an appropriate cleaner STATUS LEVEL L/MONO LEVEL RIGHT FREQ NORMAL BYPASS such as non-ammonia Windex® LOWPASS PHASE AUTO STDBY INPUT... - Page 12 343 Vanderbilt Avenue Norwood,MA 02062 (781) 762-6300 www.atlantictechnology.com 015-0610-A...
