Merlin (Chamberlain) Openers

Push Button ( Bell Press ) terminal locations.
Please check your garage door opener manual for more information.
MR650/MR850
Bell/Push button terminals
MR655EVO QuietDrive Pro
MR855EVO SilentDrive Pro
MR655MYQ SilentDrive Essential
MR855MYQ SilentDrive Elite
Bell/Push button terminals
MR60 / SR60 Roller Ace
MR600 / MR800
Bell/Push button terminals
11
MR550EVO WeatherDrive
Bell/Push button terminals
MR650EVO QuietDrive
MR850EVO SilentDrive / MR850BBU
MRC950EVO OverDrive
Bell/Push button terminals
MR1000 / M430R / MT230 / MT230T
Bell/Push button terminals
MS65MYQ Commander Essential
MS105MYQ Commander Elite
MS125MYQ Commander Extreme
Bell/Push button terminals
MJ3800 / MJ3800R
Bell/Push button terminals
MJ3800MYQ Commander Ultimate
Bell/Push button terminals
MT60EVO PowerAce, MT100EVO
TiltMaster, MT120EVO CyclonePro
MT110MYQ Commander MYQ
Bell/Push button terminals
MT3850 / MT3850EVO
MT5580 / MT5580P
Bell/Push button terminals
MT600 / MT800 / MT1000
Bell/Push button terminals
MT60 / MT60P
Bell/Push button
terminals
MT50EVO EntryLift / ST50EVO
Bell/Push button
terminals
