- Page 1 1800 427 243 ST50EVOB ST50EVOC Sectional Garage Door Opener Installation and Operating Instructions Owners Copy: SAVE THESE INSTRUCTIONS for future reference This manual contains IMPORTANT SAFETY information DO NOT PROCEED WITH THE INSTALLATION BEFORE READING THOROUGHLY...
-
Page 2: Table Of Contents
Sticking, binding or unbalanced doors must be repaired interfere with the proper operation of the Safety Reverse System before installing this opener. SPECIAL NOTE: Steel-line strongly recommends that The or damage the garage door. Do not wear rings, watches or loose clothing while Protector System be installed on all garage door openers. -
Page 3: Before You Begin
BEFORE YOU BEGIN: 1. Check the wall and ceiling above the garage door. (The opener and lintel bracket must be securely fastened to structural supports.) 2. Do you have a finished ceiling in your garage? If so, a support bracket and additional fastening hardware (not supplied) may be required. -
Page 4: Carton Inventory
(14) Rail mounting bracket gomerlin.com.au gomerlin.co.nz Manual MT50EVO Sectional Garage Door Opener www.steel-line.com.au Ph: 1800 427 243 Installation and Operating Instructions 132A2890 Owners Copy: SAVE THESE INSTRUCTIONS for future reference This manual contains IMPORTANT SAFETY information DO NOT PROCEED WITH THE INSTALLATION BEFORE READING THOROUGHLY... -
Page 5: Tools Required
TOOLS REQUIRED Drill Bits HARDWARE PROVIDED (1) Clevis pin 80 mm (2) R clip (3) Hexagonal head screw M8 1 (1x) 2 (1x) 3 (6x) 4 (6x) (4) Nut M8 (5) Flat washer M8 (6) Clevis Pin 5 (6x) (7) R clip 8 (8x) 7 (1x) 9 (8x) -
Page 6: Control Panel
CONTROL PANEL (located under the lens cover) 1. Terminal Block: used for external accessories (see chart below). Function Polarity Comment Push button Dry contact input for push button wired wall controls: Common Common terminal for push button and IR Beams: Common Common terminal for push button and IR Beams: IR Sensor... -
Page 7: Assembly
ASSEMBLY SECTION ASSEMBLING THE 3 PIECE SEGMENTED RAIL The segmented rail is largely preassembled and consists of 3 parts. The carriage, push rod, release handle, the guide pulley and the lintel bracket with belt/chain tensioner are in the front part (A). The seating for the drive shaft and the sprocket are in the rear part (B). -
Page 8: Installation
INSTALLATION SECTION Wear protective goggles when working overhead to protect your eyes from injury. Disengage all existing garage door locks to avoid damage to the garage door. To avoid serious personal injury from entanglement, remove all ropes connected to the garage door before installing the opener. -
Page 9: Sectional Door
POSITION THE OPENER Disengage the trolley mechanism (see section 18 “Operating the manual release”) and slide it back towards the powerhead. Secure the hanging push arm up into the rail assembly temporarily using tape or rope, to avoid a hazard. SECTIONAL DOOR You will need a 50 mm piece of timber or similar spacer to gauge the distance between door and rail. - Page 10 HANG THE OPENER The opener must be securely fastened to a sound structural support above the opener. fig.1 1.Postion the opener as in the previous step. Check the rail is centred over the door. Ensure the rail brackets (fig.1) is on the Powerhead end of the rail in a position as close to the opener as possible (X).
-
Page 11: Operate The Manual Release
Make sure the garage door is fully closed. Pull the manual release cord ATTACH DOOR ARM TO TROLLEY to disengage the trolley. Slide the trolley to around 300 mm from the Fig. 1 lintel bracket. 1.The straight door arm is already preassembled to the trolley. 2.Install the curved arm (1) onto the door bracket using the 23 mm Clevis pin (2) and R-Clip (3) supplied. -
Page 12: Adjustment
Connect Electric Power TO AVOID INSTALLATION DIFFICULTIES, DO NOT RUN THE GARAGE DOOR OPENER UNTIL INSTRUCTED TO DO SO. Connect to properly fused and earthed power outlet. - Ensure all ropes and installation tools have been removed from the door. - When the opener is switched ON, the operator light flashes a number of times and then remains ON. -
Page 13: Test Safety Reverse System
When the door reverses off the 40 mm high obstacle, remove the obstacle and run the opener through a complete travel cycle. Door must not reverse in closed position. If it does, repeat Program the Limits and Force then repeat safety reverse test. If continuous reversals occur, contact your local Steel-line branch. 40mm... -
Page 14: Install The Protector System (Optional)
To prevent entrapment, install The Protector over 400 N (40 kgf). System™ (IR BEAMS) no higher than 100 mm above the floor. SPECIAL NOTE: Steel-Line strongly recommends that The Protector System (IR BEAMS) be installed on all garage Disconnect power to the garage door opener door openers. -
Page 15: Install Wireless Wall Button
• Attach to the wall using the two screws provided. If mounting to a plaster wall, wall plugs may be required. NOTE: Do not overtighten screws. • Replace the front cover plate. INSTALL WARNING LABELS steel-line.com.au ph : 1800 427 243 For Service Call RISK OF ENTRAPMENT Installation Date Repeat Safety Reverse Test monthly. -
Page 16: Wireless Programming
WIRELESS PROGRAMMING (OPTIONAL ACCESSORIES) Activate the opener only when door is in full view, free of obstruction and properly adjusted. No one should enter or leave garage while door is in motion. Do not allow children to operate push button(s) or remote(s). Do not allow children to play near the door. -
Page 17: Using Your Opener
MAINTENANCE AND CARE OF YOUR OPENER Battery of the remote control: USING YOUR OPENER REPLACE BATTERIES IN REMOTES 1. Your opener can be activated by any of the following devices: • Opener control panel: UP and DOWN Buttons and Blue Open- The batteries in the remote have an extremely long life. -
Page 18: Accessories
774ANZ NOTE: Only genuine ccessories are approved for use with this opener. Generic compatible accessories are NOT approved for use with this opener. SPECIFICATIONS - STEEL-LINE - ST50EVOB / ST50EVOC Input Voltage....230-240 Vac, 50 Hz Max. Pull Force ....500 N Power ......80 Watt... -
Page 19: Troubleshooting
TROUBLE SHOOTING 1. Opener doesn't operate from either door control or 7. Door opens but won't close: remote: • Check The Protector System™ (if you have installed • Does the opener have electric power? Plug lamp into this accessory). If the light on the Beams are flashing, outlet. -
Page 20: Warranty
Except as set out in the Australian Consumer Law (being Schedule 2 of the Competition and Consumer Act 2010) (as amended, consolidated or replaced): All other guarantees, warranties and representations in relation to the Unit or its supply are excluded to the extent that Steel-Line can lawfully exclude them;...
